fast cured 2 part clear Polyurethane encapsulant for weighing cell JES127
- Category: >>>
- Supplier: Shanghai Joyfree Co. Ltd.
Share on (1600540392423):
Product Overview
Description
Product Advantage
Product Data
ITEM | JES-127 | |
Appearance | A:BLight yellow liquid B: Brown liquid | |
Mixed Viscosity, cps, 25℃ | 1400 | |
Viscosity, cps, 25℃ | A/B 800/100 | |
Density, g/cm3, 25℃ | 0.96±0.05 | |
Mix rate, by weight | A : B = 2.8:1 | |
Potting time,100g, min, 25℃ | 30 | |
Cured condition | 25℃ 70mins | |
Hardness, shore A | 67 | |
Feature after cured | 150 | |
Thermal Conductivity, W/M.K | 0.25 | |
Dielectric strength | >18 kV/mm | |
Volume resistant（DC500V）Ω·CM | 1×1012 | |
Temperature Range,℃, | -60～100 | |
Dielectric loss factor | 0.02 | |
Product Usage
Application
APPLICATION
It is supplied in lot matched kits consisting of Part A and Part B in separate containers.
During long periods of storage, some of the filler may settle at the bottom of the containers and should be individually homogenised prior to use.
The two components should be thoroughly mixed using a weight ratio of 1:1 until the mixture has a uniform colour. Vacuum de-airing is recommended. A residual pressure of 10-20 mm mercury applied for 5-10 minutes will sufficiently de-air the material
A/B black polyurethane filling polyurethane for potting casting lights
Package
Part A: 25kg/barrel、200kg/Drum
Part B: 25kg/barrel、200kg/Drum
Delivery Time
below 2000KGs 7-15days
5000-20000KGs 15-25days
Shipping way
Samples: DHL, Fedex, TNT etc.
Cargo: By sea, by air, by railway etc.
fast cured 2 part clear Polyurethane encapsulant for weighing cell JES127
