JIS Standard U Channel C Channel Carbon Steel Channels
- Category: >>>
- Supplier: Zhongdu Metal (shandong) Co. Ltd.
Share on (1600544130771):
Product Overview
Description
Video description
A36 A572 GR50 A992 SS400 carbon structural steel U C channel
U / C Channel steel
Channel steel is a long bar of steel with a grooved cross section. It is carbon structural steel used in construction and machinery. It is a section steel with complex sections. Its cross-sectional shape is slotted. Channel steel is mainly used in building structure, curtain wall engineering, mechanical equipment and vehicle manufacturing.
Product Name | JIS Standard U Channel C Channel Carbon Steel Channels |
Type | u channel /c channel |
Standard | JIS,GB,EN,AiSi,ASTM,bs,DIN |
Length | 1000-12000mm |
Grade | Q195-Q345/SS400/ss335/ST41/ST50 |
Certificate | ce, ISO9001 |
Technique | Hot Rolled Based |
Strength of extension | A36/420MPa S355JR/485MPa |
Tolerance | ±1% |
Processing Service | Welding, Punching, Cutting, Bending, Decoiling |
Spangle Type | Regular Spangle |
Hardness | Mid Hard |
Delivery Time | 10-20 days |
MOQ | 1 Ton |
Payment term | L/C T/T (30% Deposit) |
Packing | Standard Seaworthy Packing |
SPECIFICATION | SIZE | KG/M |
5# | 50*37*4.5 | 5.438 |
6.3# | 63*40*4.8 | 6.634 |
8# | 80*43*5.0 | 8.045 |
10# | 100*48*5.3 | 10.007 |
12# | 120*53*5.5 | 12.059 |
14#A | 140*58*6.0 | 14.535 |
14#B | 140*60*8.0 | 16.733 |
16#A | 160*63*6.5 | 17.24 |
16#B | 160*65*8.5 | 19.752 |
18#A | 180*68*7.0 | 20.174 |
18#B | 180*70*9.0 | 23 |
20#A | 200*73*7.0 | 22.337 |
20#B | 200*75*9.0 | 25.777 |
22#A | 220*77*7.0 | 24.999 |
22#B | 220*79*9.0 | 28.453 |
25#A | 250*78*7.0 | 27.41 |
25#B | 250*80*9.0 | 31.335 |
25#C | 250*82*11.0 | 35.26 |
28#A | 280*82*7.5 | 31.427 |
28#B | 280*84*9.5 | 35.823 |
28#C | 280*86*11.5 | 40.219 |
30#A | 300*85*7.5 | 34.463 |
30#B | 300*87*9.5 | 39.173 |
30#C | 300*89*11.5 | 43.883 |
32#A | 320*88*8.0 | 38.083 |
32#B | 320*90*10.0 | 43.107 |
32#C | 320*92*12.0 | 48.131 |
36#A | 360*96*9.0 | 47.814 |
36#B | 360*98*11.0 | 53.466 |
36#C | 360*100*13.0 | 59.118 |
40#A | 400*100*10.5 | 58.928 |
40#B | 400*102*12.5 | 65.204 |
40#C | 400*104*14.5 | 71.488 |
Zhongdu Metal (Shandong) Co., Ltd
Zhongdu Metal (Shandong) Co., Ltd. was established in 2008 with a total investment of more than 90 million yuan and 350 employees. Mainly export carbon steel\\Stainless steel and galvanized products. With diversified development as the core, the company integrates the production, processing and trade of various steel pipes, profiles, stainless steel sheets and coils, and galvanized coils to create a comprehensive international trading company integrating industry and trade. Our products are mainly exported to South America, Southeast Asia, Africa, Russia, Ukraine. We have at least 14 years of experience in steel product production and research and development, and accept most customized products of all materials. The users are in the national economic fields such as chemical industry, machinery, construction, public utilities, shipbuilding, petroleum and so on. With a professional team, rich product resources and perfect management system, we continue to improve our competitiveness and provide customers with high- quality products and satisfactory services. The company adheres to the principle of 'Quality First, Honesty First, Customer First'. Welcome new and old customers from all walks of life to contact us to establish future business relationships and common development!
Our service:
1. More than 14 years manufacturer experience and have been exported over 100 countries.
2. All kinds of steel products: carbon steel , galvanized steel products, stainless products. Including: pipe, coil, sheet,channel, bar, structure steel, nail, wire and so on.
3. 100% quantity and quality assurance.
4. 1 year service after-sales.
5. All specification of steel products is available with factory price.
5. All specification of steel products is available with factory price.
1.Seaworthy Package
2. Customized is accepted.
U-beam steel is widely used, mainly used for: various civil and industrial building structures; various large-span industrial
plants and modern high-rise buildings, especially industrial plants in areas with frequent seismic activities and high-temperature working conditions; large load-bearing capacity and cross-section are required Large-scale bridges with good stability and large spans; heavy equipment; highways; ship skeletons; mine supports; foundation treatment and embankment engineering; various mechanical components.
If you are interested in our products, please provide the following in advance:
1. Color & thickness & length & quantity
2. Delivery time
3. Packing request
4. Other request details
1. Color & thickness & length & quantity
2. Delivery time
3. Packing request
4. Other request details
1. who are we?
We are based in Shandong, China, start from 2020,sell to Domestic Market(50.00%),North America(10.00%),Southeast Asia(8.00%),Africa(8.00%),Eastern Europe(5.00%),Mid East(5.00%),South Asia(5.00%),South America(2.00%),Oceania(2.00%),Eastern Asia(00.00%),Western Europe(00.00%),Central America(00.00%),Northern Europe(00.00%),Southern Europe(00.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Seamless Steel Pipe,Carbon Steel Plate,Stainless Steel Pipe,Stainless Steel Plate,Steel Bar
4. why should you buy from us not from other suppliers?
We have at least 14 years of experience in steel product production and research and development, and accept most customized products of all materials.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
We are based in Shandong, China, start from 2020,sell to Domestic Market(50.00%),North America(10.00%),Southeast Asia(8.00%),Africa(8.00%),Eastern Europe(5.00%),Mid East(5.00%),South Asia(5.00%),South America(2.00%),Oceania(2.00%),Eastern Asia(00.00%),Western Europe(00.00%),Central America(00.00%),Northern Europe(00.00%),Southern Europe(00.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Seamless Steel Pipe,Carbon Steel Plate,Stainless Steel Pipe,Stainless Steel Plate,Steel Bar
4. why should you buy from us not from other suppliers?
We have at least 14 years of experience in steel product production and research and development, and accept most customized products of all materials.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
