Ansi/astm D2863 Oxygen Index Meter Digital Oxygen Index Apparatus For Lab

1. Compliant standards:

1.1 Comply with GB/T2406.2-2009 "Plastics—Determination of flammability by oxygen index" and JIS7201, BS2782, ANSI/ASTM, D2863, ISO4589-2:1996 test standards.

2. Scope of application:

2.1 It's applicable to strip or sheet materials with sample thickness less than 10.5mm that can self-supporting upright, and also suitable for homogeneous solid materials, laminates, foam materials, soft sheets and film materials with apparent density greater than 100kg/m³ and some foam materials with an apparent density of less than 100 kg/m³, and a test method for sheet-like materials or films that can be self-supporting upright is provided for judging the ease of combustion of materials in contact with flame in air.

3.1 Oxygen concentration (oxygen index): direct reading by digital display. Resolution: 0.1%.

3.2 Air supply pipeline: flow meter, pressure gauge and needle valve.

3.3 Combustion cylinder: Quartz glass cylinder, inner diameter: 75mm, height: 450mm

3.4 Ignition: dedicated propane hand-held electronic electric firearm. Using a copper tube with a diameter of 2.0mm, the flame can be adjusted to spray 16mm±4mm vertically downward from the outlet.

3.5 Glass beads: φ4.5mm, filling height 95mm

3.6 Specimen clamps: one set of hard self-supporting material and one set of soft material clamp

3.7 Gas source: Oxygen and nitrogen with a purity of more than 98% (provided by the buyer)

3.8 Power requirements: AC220 (±10%) V/50HZ.

3.9 Dimensions: L630*W350*H655 (unit: mm)

Q: What's the material of machine?
A: Cast iron, stainless steel
Q: Do you accept customization service?
A: Yes, we accept non-standard customized testing apparatus.
Q: What's the production time?
A: In general, the delivery time will be about 45-55 working

days after deposit receipt. If you're in urgent need, we could

try to produce your order in advance.
Q: What's the warranty and after sales service?
A: Our warranty is one year. Within warranty, after sales service

is for free. For after sales service, we will dispatch our engineer

for commissioning at customer's place. The air tickets and

accommodations are covered by our customer. Besides, we

offer commissioning by video guidance.
Q: What's the Packaging?
A: Usually, all the machines are packed by wooden case. For

small machines and components, it is packed by carton.
Q: What's the payment term?
A: T/T, L/C and other payment terms could be negotiated.
