100L 300L Солнечный водонагреватель без давления из нержавеющей стали
- Category: Solar Water Heaters >>>
- Supplier: Jiangsu Imposol New Energy Co. Ltd.
Share on (1600544888340):
Product Overview
Description
| Main Specifications : | |||||
| 1) Inner tank: Stainless steel SUS304-0.5mm-360mm | |||||
| 2) Outer tank:Stainless steel SUS201-0.4mm(SS)-460mm | |||||
| 3) 80mm distance between vacuum tubes | |||||
| 4) Insulation: Polyurethane 55mm | |||||
| 5) Vacuum tube: ALN/ALN-SS/CU coating 58/1800mm | |||||
| 6) Frame: SUS201-1.2mm /Aluminum alloy 2.5mm frame | |||||
| 7) stainless steel SUS 304 bolts | |||||
| 8)Silicone seal ring and dust ring | |||||
| 9) 3/4' or 1/2' inlet,outlet,air vent stainless steel SUS304- 2.0mm | |||||
| Optional accessories : | |||||
| 1) Reflector:aluminum component | |||||
| 2) Electric heater : | |||||
| 3) Magnesium stick : | |||||
| 4) Assistant tank : | |||||
| 5) Solar Controller : |
| Model | Light Area(m2) | Vacuum Tube | Capacity (Liters) | 20GP/40HQ Loading Qty | ||
| Ø(mm) | L(mm) | NO . | ||||
| GS means galvanzied steel appearance | ||||||
| IPJG 100-SS | 1.4 | 58 | 1800 | 10 | 100L | 63/152 |
| IPJG 120-SS | 1.68 | 58 | 1800 | 12 | 120L | 55/135 |
| IPJG 150-SS | 2.1 | 58 | 1800 | 15 | 150L | 47/114 |
| IPJG 160-SS | 2.24 | 58 | 1800 | 16 | 160L | 44/106 |
| IPJG 180-SS | 2.52 | 58 | 1800 | 18 | 180L | 40/97 |
| IPJG 200-SS | 2.8 | 58 | 1800 | 20 | 200L | 37/89 |
| IPJG 240-SS | 3.36 | 58 | 1800 | 24 | 240L | 32/77 |
| IPJG 250-SS | 3.5 | 58 | 1800 | 25 | 250L | 31/75 |
| IPJG 300-SS | 4.2 | 58 | 1800 | 30 | 300L | 26/64 |
FAQ
Q1,Can I have a sample for testing?
A: Yes,of courses we can supply the sample for you !
Q2:Can I add my logo on the water tank
A:Yes,OEM and ODM are available for us.But you should send us LOGO image
Q3: How can i get the after-service?
A:We will send you the spare parts by free if the problems caused by us.
If it is the men-made problems,we also send the spare parts,but you should pay.
Q4:Do you have inspection before delivery
A:100% self-inspection before packing
Q5 :Can I have a visit to your factory before the order?
A: Sure,welcome to visit our factory.Here is our factory address:No. 5 Shengda Road, Konggang Industrial Park ,Luoxi Town, Xinbei District, Changzhou City, Jiangsu Province China
Why Choose Us?
1.OEM is accepted;
2.Our Product is durable and has a long service life;
3.We have rich production experience.The quality of Product is reliable;
4.We have a perfect production process and strict quality control system;
5.We have perfect service system and will give you the best service.
6.Professional Production Line
