GZCOM 1800M IPQ6000 mu mimo BLE Openwrt 11AX WIFI 6 1000mw wireless outdoor ap router
- Category: >>>
- Supplier: Shenzhen Gzcom Communication Co. Ltd.
Share on (1600545721174):
Product Overview
Description
Product Paramenters
Hardware: | ||||||||||
Chipset | IPQ6000 | |||||||||
Standard | 802.11ax/ac/b/g/n | |||||||||
Flash | SPI NOR 8MB (1.8v) + NAND 128MB | |||||||||
DDR3L | 512MB | |||||||||
2.4G Frequency | 2.4GHz - 2.484GHz | |||||||||
2.4G Wi-Fi standard | 802.11b/g/n/ax | |||||||||
5.8G Frequency | 5150~5850MHz | |||||||||
5.8G Wi-Fi Standard | 802.11 a/n/ac/ax | |||||||||
Interface | 1 * 10/100 /1000 RJ45 WAN Port | |||||||||
1 * Reset button, press 10 seconds to revert to default setting | ||||||||||
Antenna | N type antenna connector | |||||||||
Data Rate | 1800Mbps | |||||||||
End Users | 160+ | |||||||||
2.4G RF Power | ≤ 23dBm | |||||||||
5.8G RF Power | ≤ 23dBm | |||||||||
2.4G Receive Sensitivity | 802.11b | 11M | -90dBm | 1M | -98dBm | |||||
802.11g | 54M | -77dBm | 6M | -93dBm | ||||||
802.11n HT20 | MCS7 | -72dBm | MCS0 | -92dBm | ||||||
802.11n HT40 | MCS7 | -71dBm | MCS0 | -90dBm | ||||||
802.11ax HT20 | MCS11 | -63dBm | MCS0 | -93dBm | ||||||
802.11ax HT40 | MCS11 | -60dBm | MCS0 | -91dBm | ||||||
5.8G Receive Sensitivity | 802.11a | 54M | -77dBm | 6M | -95dBm | |||||
802.11n HT20 | MCS7 | -75dBm | MCS0 | -93dBm | ||||||
802.11n HT40 | MCS7 | -72dBm | MCS0 | -91dBm | ||||||
802.11ac HT20 | MCS7 | -74dBm | MCS0 | -93dBm | ||||||
802.11ac HT40 | MCS7 | -72dBm | MCS0 | -91dBm | ||||||
802.11ac HT80 | MCS9 | -62dBm | MCS0 | -88dBm | ||||||
802.11ax HT20 | MCS11 | -63dBm | MCS0 | -93dBm | ||||||
802.11ax HT40 | MCS11 | -60dBm | MCS0 | -90dBm | ||||||
802.11ax HT80 | MCS11 | -56dBm | MCS0 | -87dBm | ||||||
2.4G EVM | 802.11b: ≤-10 dB; 802.11g: ≤-25 dB; 802.11n: ≤-28dB ; 802.11ac: ≤-32 dB; 802.11ax: ≤-35 dB | |||||||||
5G EVM | 802.11a: ≤-25 dB; 802.11n: ≤-28 dB; 802.11ac: ≤-32 dB; 802.11ax: ≤-35 dB | |||||||||
PPM | ±20ppm | |||||||||
PoE | 48V (IEEE 802.3at) | |||||||||
LED light | Sys, WAN, LAN | |||||||||
Power Consumption | ≤ 24W | |||||||||
Size | 295*231*80MM | |||||||||
Weight | 3.5KG | |||||||||
Others: | ||||||||||
Environment | Operating Temperature: -20~45 ℃ Limit working temperature: -30~70 ℃ Storage Temperature: 0~70 ℃ Humidity: 5%~95% non-condensing | |||||||||
