GZCOM CAPWAP Protocol Enterprise Gateway & AC Controller, AP controller, remote management support
- Category: >>>
- Supplier: Shenzhen Gzcom Communication Co. Ltd.
Share on (1600545740130):
Product Overview
Description
Product Description
GZ-AC-BW260 is an middle size Enterprise Gateway based on CAPWAP protocol,support PPPoE/DHCP/Static IP access.
GZ-AC-BW260 is an middle size Enterprise Gateway based on CAPWAP protocol. Support Load Balance, Ethernet backup and Ethernet Superimposed, multi-ISP access; then support DHCP, policy routing and VPN, together with Smart flow control, Abundant security, varied user management and multiple authentication function, it consistent to provide high efficiency and professional network connectivity for hotel, enterprise, Internet bar, shopping mall. What’s more, it can manage the wireless access point fast and stable in central and remote, provide whole wireless coverage solution, cost saved and convenient.
Product Paramenters
Model | GZ-AC-BW260 | |
Protocol | IEEE 802.3, 802.3u, 802.3ab TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DDNS, IPsec, PPTP, L2TP, CAPWAP Protocol | |
CPU | MT7621 | |
DDR | 512M | |
Flash | 16M | |
Heat Dissipate | Super silent ball fan | |
Ports | 4 × 10/100/1000Mbps LAN ports (can set to WAN port) | |
1 × 10/100/1000Mbps WAN port | ||
Power | AC:100-240V,50HZ | |
Dimension | 440mm*240mm*44mm | |
Working Temperature | -20℃~55℃ | |
Storage Temperature | -40℃ ~ 70℃ | |
Working Humidity | 5% ~ 97%RH (No condensation) | |
Firmware features | ||
AP Management | Max to access and manage 256 users | |
Max to manage 256PCS wireless AP | ||
Centrally and remotely to manage/configure wireless AP | ||
View user’s status | ||
Smart Flow Control | One click smart flow control | |
Powerful multiline diversion | ||
Application Priority Automatically | ||
Load Balance | Multiple WAN, multiple ISP network access | |
Intelligence load balance | ||
Ethernet line backup | ||
Ethernet Superimposed | ||
Policy routing: based on IP address, destination IP address, source MAC address, network port, domain, destination port, Extranet port, Identity binding | ||
Protocol binding | ||
Routing | Static Routing | |
Behavior Management | All-round to block P2P firmware | |
P2P flow control and bandwidth allot | ||
File and URL filter | ||
Monitor network behavior at all times | ||
VPN | L2TP, PPTP, VTUNS | |
Bandwidth limitation | IP-based bandwidth limitation | |
Safeguard / Restrict bandwidth | ||
Time strategy | ||
IP based session restriction | ||
Security Center | MAC address filter | |
UPR/key words filter | ||
Web content filter | ||
IP address filter | ||
Port mapping | ||
DMZ | ||
Defense Center | TCP/UDP/ICMP flood defense | |
Block TCP scanning | ||
Block ping WAN port | ||
ARP Detection | Send GARP packets | |
ARP Scanning on WAN/LAN port | ||
Online detection | ||
IP-MAC binding | ||
Authentication | PPPoE authentication | |
Portal authentication like Wechat Authentication, WEB password authentication, One-time password authentication, SMS authentication | ||
IP and MAC authentication: Allow/deny user access by IP/MAC address | ||
Management | Web/CLI/Telnet management | |
Remote management | ||
Others | DDNS, VPN management | |
Content | AC-BW260 *1 | |
Power Cable *1 | ||
Installation Accessory | ||
QIG*1 | ||
