BIOBASE Popular China Gas Chromatograph High precision Gas Flow Control System
- Category: Other Analysis Instruments >>>
- Supplier: Biobase Kings Co. Ltd.
Share on (1600546643424):
Product Overview
Description
Product Description
Features:High-precision gas flow control system (EPC)
* High-precision gas flow control, to ensure the accuracy of GC analysis, to ensure the efficiency of daily analysis, EPC control
accuracy 0.01psi.
* It realizes the self-protection of gas circuit failure, automatic ignition, re-ignition, automatic opening of the gas circuit,
and one-key start.
* A variety of control combination modes of operation, automatic pressure and flow adjustment, control and display, can operate in
gas-saving mode.
Color widescreen, unique design of touch keys
* 7-inch industrial color LCD screen design, more complete display information, more reasonable
interface operation.
* Have two sets of operating systems in Chinese and English to meet different user needs.
* Adopt resistive touch screen, feel good, durable, double operation of screen and software to achieve seamless connection.
Leading structural design
* Modular structure design, easy to upgrade, can be equipped with a variety of high-performance detectors such as FID, TCD,ECD,
FPD and NPD, etc., to meet the analysis needs of complex samples.
* Advanced sampler design, unique liner structure and special processing technology to ensure zero adsorption of samples. * Adapt
to a variety of sample injection methods such as: headspace sampler, thermal desorption analyzer, liquid automatic sampler, easily
competent for the analysis of various sample types.
* Timed self-starting program can easily complete the laboratory online analysis of gas and liquid samples. Humanized software
operating system
* Adopt advanced 10/100M self-adaptive Ethernet communication interface, built-in IP protocol stack,
easily form a local area network, realize long-distance transmission, remote control, and remote diagnosis.
* Equipped with IBrainChrom workstation, which can support multiple chromatographs (253 sets) to work at the same time, realize
data processing and reverse control.
Data processing and countermeasures
* Have complete audit trail, user rights management, electronic signature and other functions, so that data and documents meet GMP
management requirements.
* The built-in Modbus/TCP server of IBrainChrom workstation can easily connect the analysis results to DCS (distributed control
system).
* 3 independent connection threads that can be connected to local, laboratory supervisors and authorities, allowing them to
monitor the operation of the instrument and analyze the data in real time.
* High-precision gas flow control, to ensure the accuracy of GC analysis, to ensure the efficiency of daily analysis, EPC control
accuracy 0.01psi.
* It realizes the self-protection of gas circuit failure, automatic ignition, re-ignition, automatic opening of the gas circuit,
and one-key start.
* A variety of control combination modes of operation, automatic pressure and flow adjustment, control and display, can operate in
gas-saving mode.
Color widescreen, unique design of touch keys
* 7-inch industrial color LCD screen design, more complete display information, more reasonable
interface operation.
* Have two sets of operating systems in Chinese and English to meet different user needs.
* Adopt resistive touch screen, feel good, durable, double operation of screen and software to achieve seamless connection.
Leading structural design
* Modular structure design, easy to upgrade, can be equipped with a variety of high-performance detectors such as FID, TCD,ECD,
FPD and NPD, etc., to meet the analysis needs of complex samples.
* Advanced sampler design, unique liner structure and special processing technology to ensure zero adsorption of samples. * Adapt
to a variety of sample injection methods such as: headspace sampler, thermal desorption analyzer, liquid automatic sampler, easily
competent for the analysis of various sample types.
* Timed self-starting program can easily complete the laboratory online analysis of gas and liquid samples. Humanized software
operating system
* Adopt advanced 10/100M self-adaptive Ethernet communication interface, built-in IP protocol stack,
easily form a local area network, realize long-distance transmission, remote control, and remote diagnosis.
* Equipped with IBrainChrom workstation, which can support multiple chromatographs (253 sets) to work at the same time, realize
data processing and reverse control.
Data processing and countermeasures
* Have complete audit trail, user rights management, electronic signature and other functions, so that data and documents meet GMP
management requirements.
* The built-in Modbus/TCP server of IBrainChrom workstation can easily connect the analysis results to DCS (distributed control
system).
* 3 independent connection threads that can be connected to local, laboratory supervisors and authorities, allowing them to
monitor the operation of the instrument and analyze the data in real time.
Specification
Model | BK-GC901 | ||
Oven | Temp. Range | RT+5~450℃ | |
Temp. Accuracy | ≤±0.1℃ | ||
Temp. Program | 16-phase | ||
Max. Temp. Heating Rate | 40℃/min | ||
Time Range | 0-999min | ||
Internal Size | 250*270*170mm | ||
Detector | Hydrogen Flame Ionization Detector (FID) | Detection limit:≤5×10-12g/s (100ng/(µl n-hexadecane-isooctane solution) | |
Temperature 450℃ | |||
Compatible with packed and capillary columns | |||
Baseline drift:≤2x10-13A/30min | |||
Baseline noise: 3×10-14A | |||
Linear range:≥107 | |||
Thermal Conductivity Detector (TCD) | Sensitivity: >5000mv.ml/mg (50mg/ml toluene-benzene solution) | ||
Temperature 400℃ | |||
Baseline drift:≤0.1mV/30min | |||
Baseline noise: 0.03mV | |||
Linear range:≥105(±10%) | |||
Flame Photometric Detector (FPD) | Detection limit:≤5×10-12g/s(S of 10ng/(µl methyl parathion-ethanol solution) Detection limit:≤4×10-12g/s(P of 10ng/(µl methyl parathion-ethanol solution) | ||
Linear range (S): ≥103 Linear range (P): ≥104 | |||
Temperature 350℃ | |||
Power Supply | AC220V±10%, 50/60Hz | ||
Standard Accessory | FID detector, Chromatography workstation software, Capillary sampler | ||
Optional Accessory | Sample injection system, TCD, FPD detector, Chromatographic column | ||
Package Size (W*D*H) | 750*710*720mm | ||
Gross Weight | 70kg | ||
