FA538 Ring spinning machine for cotton yarn
- Category: Spinning Machines >>>
- Supplier: Qingdao,Tongda,Textile,Machinery,Co.,Ltd.
Share on:
Product Overview
Description
FA538 Ring spinning machine cotton ring spinning frame machine
Product Display
FA538 Technical Data and Specifications: | |
Spindle gauge | 70mm |
Lifting | 205 180 155 mm |
Ring Diameter | Φ45,Φ42,Φ38mm |
Number of Spindle | 384,396,408,420,432,444,456,468,480,492,504,516 |
Yarn count | 97.2---4.9tex (6--12Ne) |
Twist | 300--1600(T/m) |
Draft Ratio | 10-50 |
Spindle speed | 19000-25000 rpm |
Spindle drive | Single tension pulley,Z or S twist optional |
Spindle wharve diameter | Φ22,Φ24,Φ20.5mm |
Creel | One tier hanger, Four or six rows optional |
Main Motor(380v50Hz) | 15/7KW 17/9KW 18.5/11KW 22/11KW (380v) |
Suction Motor (380v 59 Hz) | 1.5KW(for No.of spindles below 444) 2.2KW (for No.of spindles above 456) |
Lift Motor | 370W |
Distance between Spindle of left and right side | 700 mm |
Headstock dimensions Endstock Dimensions | Width: 640mm, length:680mm, height:1700mm Width:640mm, length:1300mm,height: 1768mm |
Total height of the machine | 2300mm |
Total length of the machine | L=2380+(N/2-1)70mm L:length N:where means the number of spindles |
Production Process
Product Categories
Factory Appearance
Our Advantage
FAQ
(1) Q: Are you a manufacturer or Trade Company?
A: We are a professional manufacturer holding our own International Trade Department, for that
we can better understand customer's needs and offer a reasonable price.
(2) Q: Are you available for on-the-spot invitation?
A: We do welcome our new and old friends come here to have a visitation.
Besides, we would send you our exposition and relative information to promote a face-to-face meeting if you'd like to.
(3) Q: Is the price offered changeable?
A: We offer reasonable price for every client, and the price is changeable according to purchasing amount.
(4) Q: How about the quality?
A:The main subassembly and raw materials are all supplied by large companies. Key parts are research and developed by our own staff. Professional assembly line work and strict quality test system can ensure your high quality requirement.
(5) Q: How's the after-sale service?
A: We offer engineers available to service overseas under merchandiser's supervision and translation.
