HYTAIS TS97 Digital Automatic Multimeter AC DC Ammeter Voltmeter True RMS Electrical Meter Resistance Electrician Tester Tool

Share on (1600546815031):


Price:$15.71 - $17.73

Quantity:


Product Overview

Description



Product Description




Specification


Basic function
Range
Accuracy
Ac Voltage(mV)
40mV/400mV
±(0.8%+5)
Ac Voltage
4V/40V/400V/750V
±(0.8%+5)
Dc Voltage(mV)
40mV/400mV
±(0.5%+3)
Dc Voltage
400mV/4V/40V/400V/1000V
±(0.5%+3)
Ac Current
400uA/4mA/40mA/400mA/20A
±(2.0%+5)
Dc Current
400uA/4mA/40mA/400mA/20A
±(1.2%+8)
Resistance(Ω)
400Ω/4k/40k/400k/4M/40M
±(1.0%+5)
Capactance
10nf-100mF
 ±(2.5%+20)
Frequency
10Hz-10MHz
±(0.1%+5)
Temperature
-40℃-1000-℃
±(1.0%+5)
Duty ratio
0.1%-99.9%
±(0.1%+5)
NCV
Continuity Test
Diode Test
Auto hold
Low Power Dispay
Maximum&Minimum test
Auto Power Off
Back light
Relative value test
LCD display - Analog bar full symbol dual display
Max Display
4000
General Characteristic
Power Supply

9V
Lcd Size

61x32mm
Meter Color:

Gray+blue
Meter Weight

358g
Meter Size

183x87x36mm
Standard Accessories:
Test lead Manual


Packing & Delivery




To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.




Company Profile










The production base of HYTAIS is located in Shenzhen,China.The company has a standard automatic flow-through debugging assembly production lines and advanced production equipment. The company strictly follows ISO9001 standards and we have a sophisticated system in product development, manufacturing, production process, QC, PMC materials, control, etc. Products are in complete accordance with international quality certification standards of CE, UL, ROHS .
HYTAIS will carry on the corporation culture of" innovation , quality and continuous improvement". We will be more efficient for the sale of domestic and international markets to provide better service. We will continue to optimize the product research and development products to our ongoing effort to research and development results, in order to provide our clients with a more professional electronic measurement tools.
Our strict scientific management system, professional and technical personnel have created a series of products with high-precision,
beauty and generosity. The main products are digital multimeter,clamp digital multimeter, non-contact testing pencil, infrared thermometer, megger and other products nearly 40 varieties.The products of HYTAIS are unique, which are of high quality, safety and reliability.We have access to a number of patented technology certificates.
