Factory selling energy saving infrared light wave dryer for ceramic production line
- Category: Building Material Machinery >>>
- Supplier: Foshan Nanhai Qihao Machinery Co. Ltd.
Share on (1600546997841):
Product Overview
Description
Product model | Outline size (mm) | Brick Inlet Width（mm） | Applicable product specifications（mm) | Lifting temperature（℃） | Power （kw） | energy consumption（kw/H） |
QH-GB066 | 2000*1268*350 | 888 | 600 | 4-9 | 10.5/21 | 2-8 |
QH- GB088 | 2000*1468*350 | 1088 | 800 | 4-9 | 10.5/21 | 2-8 |
QH- GB1088 | 2000*1668*350 | 1288 | 1000 | 4-9 | 10.5/21 | 2-10 |
QH- GB1288 | 2000*1868*350 | 1488 | 1200 | 4-9 | 21/31.5 | 2-10 |
QH- GB1588 | 2000*2068*350 | 1788 | 1500 | 4-9 | 21/31.5 | 2-12 |
No. | ITEM | Parameter |
1 | Power Supply | 380V/50HZ |
2 | Single machine power | 21kw（21 1.0kw light wave tubes, customizable） |
3 | drying temperature | ≤250℃ |
4 | Effective length | 2000mm |
5 | Effective width | 888mm/1088mm/1288/1488/1788mm |
6 | Effective height | 30-60mm |
7 | energy consumption | 200℃≈5kw/h，250℃≈8kw/h，300℃≈12kw/h |
8 | Control system | Two sets of PID intelligent control system |
9 | Feature Function 1 | Intelligent interruption function, with glaze line stop dryer at the same time stop |
10 | Feature Function2 | 8.5kw+7.5kw Group control (one group is always bright, the other is energy supplement) |
600*1200 Pu board polished glazed tile inkjet front/rear
300*300 secondary firing tile before/after inkjet
900*1800 large slab tiles before inkjet / after inkjet / after glaze
800*800 polished glazed tiles after edging
After the glass mosaic is formed
1200*2400 Super Puban tile inkjet front/rear
800*800 polished glazed tiles before/after inkjet
1200*2400 Qualified polished glazed tile after inkjet
After the honeycomb ceramic is formed
