The important factors for High Frequency Board
Dielectric Constant(DK)
Dissipation Factor(DF)
Coefficient of Thermal Expansion
Moisture Absorption
Product Description
| High Frequency PCB capabilities | ||
| Item | Content | Capability |
| 1 | Quality Standard | UL94V.0, IPC-6012, 6013, ISO-9001, ISO-14001 |
| 2 | Layers | 2-24L |
| 3 | Lead Time | 5days-3weeks |
| 4 | Material | RO4003C, RO4350B, RO3003, RO3010, RO3210, RT5880 |
| 5 | PP | Rogers 4450F, Domestic-(25FR), Domestic-(RF-27), Domestic-(6700) |
| 6 | Board size(Min-Max) | 10mm*10mm to 450mm*610mm |
| 7 | Board thickness(Min-Max) | 0.4mm-5.0mm |
| 8 | Copper thickness(Min-Max) | 0.5oz-2oz |
| 9 | Line Width/Spacing (Min) | 3/3mil |
| 10 | Impedance | +/-10% |
| 11 | Min Drill Hole Diameter | 0.15mm |
| 12 | Surface treatment | ENIG, Immersion Tin, Immersion Silver, OSP |
| 13 | Other Techniques | Peelable solder mask, Gold fingers, Carbon oil, Countersink holes, Back drill |
High Frequency PCB Main Application:
Related Products
Production Process
Company Information
Exhibition
Packaging
Bubble package, EPE package, ESD Bag,Vacuum bag
FAQ
Q1. What does Jinhua Tecenology can do?
We can support you PCB Design, PCB board manufacturing, Components or Parts Source, Surface Mount (SMT), Thru-Hole (THT),hybrid of both, Functional Test, Wire Soldering etc one stop PCB&PCBA service
Q2. For PCB quotation, what files format do JINHUA need?
Gerber, Protel 99SE, DXP, PADS 9.5, AUTOCAD, CAM350 are OK.
| Bare PCB Prototype | |
| Layer | Quick Turn |
| 2 | 24 hours |
| 4 | 48 hours |
| 6-8 | 72 hours |
Q3. What will I get from you? Are my files safe?
You will get the free DFM feedback for PCB gerber files, BOM list components feedback, Quotation feedback within 2 hours. NDA can be signed for extra security issue.
Q4. MOQ?
There is no MOQ in Jinhua Tecenology. We can offer prototype, expedite prototype, small&medium amount, big amount pcb & pcba service.
