Fishing Boat Kinocean Cabin Full Welded Aluminium Aluminum Hull Fishing Activities Professional Work 2016-2017 All Weld Optional

Share on:


Price:$8,000.00 - $8,717.00
Price in USD:Details

Quantity:


Product Overview

Description






























Product Description














OVERVIEW
An enclosed cabin with a solid aluminum bulkhead offers complete protection from the elements. The lockable cabin is perfect for securing belongings while moored or parked, and this craft can be left out in all weather conditions. This model is an excellent commuter on the waterways - so load up with groceries, friends and family and get to your destination at any time of the year! As with all of our vessels, these cabins are safe and built to last.


































































SPECIFICATIONS



Capacity (People):


4


Beam:


7'-2"


Horsepower Range:


90-115


Aft Deck Size:


69 3/4" x 68 1/2"


Cabin Size:


84" x 70 1/2" x 64"


Freeboard:


30"


Dead Rise:


16°


Fuel Tank:


20 Imp GAL


Side Plate:


1/8" 5052


Bottom Plate:


3/16" 5086


Hull Weight:


1,600 lbs


Bottom Width:


6'-0"


Tow Weight:


2,675 lbs






















































Standard Features



Fully welded hard-top with 2-piece aluminum-framed aft-leaning windshield & (2) aluminum-framed sliding side windows



Electric wiper – heavy duty wiper with self-park & switch



Non-skid paint on bow & main deck


Bow storage (open with sill)


External motor bracket for single 25″ shaft engine with auxiliary mount and full width platform


Flotation – closed cell polyurethane spray foam under decks & gunnels


Heavy duty custom hull graphic


Handrails – cabin top


Harness system – prewired, fully integrated ABYC marine harness for electrical accessories


 Fully welded aluminum cockpit deck with inspection hatches for fuel connections and wire ways


Glove box


Fish box in rear gunnel with cutting board


Cup holders


Navigation lights (LED)


Fuel tank (20 Imp Gal/90 L/24 US Gal) w/ fuel gauge – built in under deck, with filter


Battery – single SRM 24 battery including wiring, breaker & box


welded aluminum cleats


way fused switch panel on dashboard


Brackets for transducer & sacrificial anode


Passenger grab rail













Related Products


















Company Information

















FAQ





Q: Where can I find wiring schematics for my boat?


We can provide any wiring schematics.





Q: Do you have any information on boating safety?
We do offer a Boating Safety Guide. This Guide is full of useful information on safety, guidelines, and regulations. If you need information about proper boating safety on your Boat, we would be happy to send one to you.





Q: Where can I find my boat's Hull Draft information?
We do not post a definative hull draft for your safety and for warranty reasons—there are just too many variables. Motor size, the amount gear on board, the number of people, even how many gallons of gas in the tank will affect the hull draft of your boat.





Q: Why does my boat perform differently than the posted performance data?


Often performance testing is done in ideal conditions to achieve the best possible results. For example, the maximum allowable horsepower, with only one person, on a calm day, is needed to achieve the maximum performance of the boat.
