fulldepth ROV light underwater lamp depth300m Underwater detection lighting diving led 50W light
- Category: >>>
- Supplier: Yantai FullDepth Technology Co. Ltd.
Share on (1600550834363):
Product Overview
Description
Product Description
Features
ZF-LL-052 deep water lighting is a high-quality high-power waterproof LED lighting specially designed for underwater applications.
The product adopts linear drive, no stroboscopic, and the brightness can reach 5000 lumens.
1. High brightness up to 5000 lumens.
2. Adopt linear drive technology, no stroboscopic.
3. Various brightness adjustment methods such as analog voltage, PWM, RS485 serial port command, etc.
2. Adopt linear drive technology, no stroboscopic.
3. Various brightness adjustment methods such as analog voltage, PWM, RS485 serial port command, etc.
Specification
model | ZF-LL-052 |
Waterproof depth | 300 meters |
Shell material | 316L stainless steel |
brightness | 5000 lumens, positive white light |
color temperature | 6000K |
Power supply (Vin) | DC24-36V |
power | 50W |
control interface | PWM dimming (pwm voltage is 3.3V~Vin) |
Wiring Definition | Red: Power Black: Ground Yellow: Control |
weight | In air: 550g, 420g in water |
Operating mode | 1. PWM mode: brightness is continuously adjustable, PWM frequency is recommended to be 1000~10000HZ (recommended) |
Precautions | 2. Forced switch mode: the yellow wire is connected to the positive pole of the power supply, and it lights up with the highest brightness; the yellow wire is connected to the negative pole of the power supply, and it is turned off. |
Way out | The lamp is specially designed for the underwater environment, it is strictly prohibited to use it in the air, and the electricity should not exceed 30S in the air, otherwise it may cause overheating and affect the life of the lamp bead. |
