2 inch Sapphire Wafer R Plane (1 102) Single Crystal Al2O3, SSP
- Category: >>>
- Supplier: Jiangyin Maideli Advanced Materials Co. Ltd
Share on (1600552234516):
Product Overview
Description
Product Description
Detail Specifications of sapphire wafer
Diameter | 1 inch ,2inch ,3 inch ,4 inch ,5 inch ,6 inch |
Orientation | R-Plane (1-102) |
Primary flat length | 32.5 +/- 2.5mm |
Thickness | As Requested |
Warp | </=20um |
Bow | </=20um |
TTV | </=20um |
Micro-roughness | Ra</=0.3nm |
Front surface finish | Epi-polished |
Back surface finish | Fine Ground |
Micro-roughness | Ra= 0.6um to 01.4um |
Laser Marking | None |
Packing | wafer in cassette vacuum sealed,Proper packaging should be provided for wafers. |
Products Show
Packing & Delivery
Packing Details : vacuumed polybag each pc
Delivery Details : 3-30 days after order
