0.05mm tc4 gr5 titanium foil sheet price
- Category: >>>
- Supplier: Baoji Seabird Metal Material Co. Ltd.
Share on (1600554875759):
Product Overview
Description
Specification
item | 0.05mm tc4 gr5 titanium foil sheet price |
Application | the titanium alloy can also be artificial bone. |
Width | Width≤200mm |
Length | as requirement |
Technique | cold rolled |
Ti (Min) | 99.5% |
Surface finish | Cold rolling,Ra 50 um |
Features | 1.high corrosion resistance 2.low density 3.non-ferromagnetic 4.good biocompatibility |
Color | bright surface |
Standard | ASTMB265/ASTMF136 AMS4911 |
Supply Status | vacuum annealed |
Certificate | ISO9001:2015 |
application | 1.Based on High intensity,titanium products tensile strength can be up to 180Kg/mm². 2.Titanium and titanium alloy in aviation industry, is called "space metal"; In addition, in the shipbuilding industry, chemical industry, manufacturing machinery parts, telecommunications equipment, hard alloy, etc have increasingly extensive application 3.In addition, because of the titanium alloy with the human body has very good compatibility, so the titanium alloy can also be artificial bone. |
Tensile Strength | ≥850Mpa |
Key words | titanium strip |
Composition (%) | C | N | Fe | O | H | Al | v | Ti |
GR1 | ≤0.08 | ≤0.03 | ≤0.20 | ≤0.18 | ≤0.015 | -- | Bal | |
GR2 | ≤0.08 | ≤0.03 | ≤0.30 | ≤0.25 | ≤0.015 | --- | Bal | |
GR5 | ≤0.10 | ≤0.05 | ≤0.30 | ≤0.20 | ≤0.015 | 5.50-6.80 | 3.50-4.50 | Bal |
Tensile Strength | Yield Strength 0.2% Offset | Yield Strength 0.2% Offset | Elongation in 2 in.or 50mm min.% | |||||
Min | Min | Min Max | Under 0.070 in.(1.8mm)in thickness | |||||
KSI | MPA | Ksi MPA KSI MPA | ||||||
1 | 35 | 240 | 20 138 45 310 | 24 | 1.5T | |||
2 | 50 | 345 | 40 275 65 450 | 20 | 2T | |||
3 | 65 | 450 | 55 380 80 550 | 18 | 2.5T | |||
4 | 80 | 550 | 70 483 95 655 | 15 | 3T | |||
Company Profile
Baoji Seabird Metal Materials Co.,Ltd was established in 2001,which occupies 21000 square meters.It is located in Baoji,Shaanxi ,China.The company is approved by ISO9000 and SGS certification .
It owns complete equipments from the raw material to finished products,such as TWO Vacuum Medium-frequency Induction Furnace,ULVAR,Two-roller Hot Rolling machine,Four-roller Cold Rolling machine,Two units Plate Leveling machine,Three Cutting Machine,Resistance Furnace,Cylindrical Grinder and so on.
Some products have reached the leading position in China. Such as, medical nitinol sheet and wire,especially two-way shape memory alloy sheet and spring ,as well as porous tungsten rod,etc.
We have two scientists in R&D Department. They have 20years experience on researching nitinol products. They all came from the Northwest Institut .This is our competitive power compare with others.
In 2009,our company expanded our business into overseas market ,and cooperated with over 100 companies and Institutes in past 7years,they are from US,UK,Germany,Singapore and so on. We believe we will make a great progress with many customers.And will porvide the more and more higher quality products and service.
It owns complete equipments from the raw material to finished products,such as TWO Vacuum Medium-frequency Induction Furnace,ULVAR,Two-roller Hot Rolling machine,Four-roller Cold Rolling machine,Two units Plate Leveling machine,Three Cutting Machine,Resistance Furnace,Cylindrical Grinder and so on.
Some products have reached the leading position in China. Such as, medical nitinol sheet and wire,especially two-way shape memory alloy sheet and spring ,as well as porous tungsten rod,etc.
We have two scientists in R&D Department. They have 20years experience on researching nitinol products. They all came from the Northwest Institut .This is our competitive power compare with others.
In 2009,our company expanded our business into overseas market ,and cooperated with over 100 companies and Institutes in past 7years,they are from US,UK,Germany,Singapore and so on. We believe we will make a great progress with many customers.And will porvide the more and more higher quality products and service.
Quality Assurance
1. According to globally recognized standard,for example ASTMF.ASTM ASTMB provide third-part inspection reports,ISO Quality
Management System .
2. Visual inspection to check surface quality ,ensuring without flaw.black dot and other defects.
3. We also take Mechanics Performance Testing, Particle size test microscope ,Powder density tester, pressure testing
machine,scanning electron microscope ultrasonic flaw detector by our company before shipping .
4. Chemical composition making sure all chemical components can satisfy customers demands.
5. Mechanical property testing making sure all Nitinol products have satisfying feature before delivery.
1. According to globally recognized standard,for example ASTMF.ASTM ASTMB provide third-part inspection reports,ISO Quality
Management System .
2. Visual inspection to check surface quality ,ensuring without flaw.black dot and other defects.
3. We also take Mechanics Performance Testing, Particle size test microscope ,Powder density tester, pressure testing
machine,scanning electron microscope ultrasonic flaw detector by our company before shipping .
4. Chemical composition making sure all chemical components can satisfy customers demands.
5. Mechanical property testing making sure all Nitinol products have satisfying feature before delivery.
FAQ
Q: Are you a trading company or manufacturer ?
A: We are factory.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we can offer the samples for free and freight afforded by buyer.
Q: How can you ensure the products quality?
A: All products are manufactured according to ASTM standard, and we make 100% inspection before shippment also we can prodide the
MTC Test Certification.
Q: Can you print our logo on the products?
A: Yes, we make it by laser printing and carving.
Q: How can i make a quote for your company?
A: Please let me know the Material.Size.Quantity.
Q: What is your terms of payment ?
A: T/T, L/C
For stocks, 100% in advance;
For futures delivery, 30% in advance, the balance before shipping.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. It is 15-30 days to do new batch.
Q: Can you guarantee the prompt delivery?
A: Yes, please don't worried it. We have professional production team to work 24 hours one day.
Please don't hesitate to contac us if you like to know more. Thank you!
A: We are factory.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we can offer the samples for free and freight afforded by buyer.
Q: How can you ensure the products quality?
A: All products are manufactured according to ASTM standard, and we make 100% inspection before shippment also we can prodide the
MTC Test Certification.
Q: Can you print our logo on the products?
A: Yes, we make it by laser printing and carving.
Q: How can i make a quote for your company?
A: Please let me know the Material.Size.Quantity.
Q: What is your terms of payment ?
A: T/T, L/C
For stocks, 100% in advance;
For futures delivery, 30% in advance, the balance before shipping.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. It is 15-30 days to do new batch.
Q: Can you guarantee the prompt delivery?
A: Yes, please don't worried it. We have professional production team to work 24 hours one day.
Please don't hesitate to contac us if you like to know more. Thank you!
