Lema LT3110A однополюсный ВКЛ ВЫКЛ 15а переключатель водонепроницаемый электронный переключатель
- Category: Toggle Switches >>>
- Supplier: Zhejiang,Lema,Electrics,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
Brand | LEMA |
Model | LT3110A |
Voltage | 250V/125VAC |
Electric Current | 15A |
Mounting Holes Dimension | φ12mm |
Contact form: | ON-OFF |
Package | CARTON |
Size | 29*57.5*15.5MM |
Material | Bakelite |
Operating frequency | 30 times/min | ||||||
Initial insulation resistance | 100MΩmin.(at 500VDC) | ||||||
Initial contact resistance | 25MΩmax. | ||||||
Dielectric strength | Between non-consecutive terminals | 1,000Vrms, 50/60Hz for 1 min | |||||
Between non-current carrying metal parts and each terminal | 2,000Vrms, 50/60Hz for 1 min | ||||||
Between ground and each terminal | 2,000Vrms, 50/60Hz for 1 min | ||||||
Vibration resistance | 10-55Hz,1.5mm double amplitude | ||||||
Shock resistance | Durable: 1000m/s2(100G)max. Malfunction: 300m/s2(30G)max. | ||||||
FAQ
Q: How do you control the products’ quality? A: 100% Auto inspection machine and manual testing together before packing. | ||||||||
Q: What's your payment term? A: We usually accept T/T. Samples cost can be paid by PayPal, Western Union. | ||||||||
Q: Would you accept to use our logo? A: If you have good quantity, we can make OEM and ODM, customized specification. | ||||||||
Q: Can I get a sample for reference? A: We are glad to send samples for your testing. Samples are free, but you may need to pay the express cost. | ||||||||
Q: What is your delivery time? A: Usually it takes 15-20 working days for productions. | ||||||||
