Price:4 250,00 $ - 4 400,00 $
Price in USD:Details

Quantity:


Product Overview

Description



Product Description







Signal tracking
BDS B1, B2, B3,
GPS L1C/A, L1C, L2C, L2E, L5
GLONASS L1C/A, L1P, L2C/A,L2P, L3
SBAS  L1C/A, L5( Just for the satellites supporting L5 )
Galileo GIOVE-A, GIOVE-B, E1, E5A, E5B
QZSS,WAAS, MSAS, EGNOS, GAGAN, SBAS













            Environmental
Operating:-45℃~+60℃
Storage:-55℃~+85℃
Humidity:Non-condensing





GNSS Features
1.Positioning output rate: 1HZ~50HZ
2.Initialization time : <10s
3.Initialization reliability : >99.99%


Recommend Products




Details Images








Specification


Surveying Performance
Channel
965 Channels
Signal Tracking
BDS B1, B2, B3,
GPS L1C/A, L1C, L2C, L2E, L5
GLONASS L1C/A, L1P, L2C/A,L2P, L3
SBAS L1C/A, L5( Just for the satellites supporting L5 )
Galileo GIOVE-A, GIOVE-B, E1, E5A, E5B
QZSS,WAAS, MSAS, EGNOS, GAGAN, SBAS
GNSS Feature
Positioning output rate: 1HZ~50HZ
Initialization time : <10s
Initialization reliability : >99.99%
Positioning Precision
Code Differential GNSS Positioning
Horizontal: 0.25 m + 1 ppm
Vertical: 0.50 m + 1 ppm
SBAS positioning accuracy: typically<5m 3DRMS
Static GNSS Surveying
Horizontal: 2.5 mm + 0.5 ppm
Vertical: 5 mm + 0.5 ppm
Real-Time Kinematic Surveying (Baseline<30km)
Horizontal: 8 mm + 1 ppm
Vertical: 15 mm + 1 ppm
Horizontal: 8 mm + 0.5 ppm
Vertical: 15 mm + 0.5 ppm
Network RTK
RTK initialization time: 2~8s
Physical
Dimension
12.9cm × 11.2cm
Weigh
970g(includiing installed battery)
Material
Magnesium aluminum alloy shell
Environmental
Operating
-45℃~+60℃
Storage
-55℃~+85℃
Humidity
Non-condensing
Waterproof/Dustproof
IP67 standard,protected from long time immersion to depth of 1m
IP67 standard,fully protected against blowing dust
Shock and Vibration
Not operating: Withstand 2 meters pole drop onto the cement ground naturally
operating : Withstand 40G 10milliseconds sawtooth wave impact test
Electrical
Power consumption
2W
Battery
Rechargeable, removable Litium-ion battery
Battery Life
Single battery: 7h( static mode ) 5h( interual UHF base mode )
6h( rover mode )
Communications and Data storage
I/O Port
5PIN LEOM external power port + RS232
7PIN LEOM RS232 + USB
1 network/radio data link antenna port
SIM card slot
Wireless Modem
Integrated internal radio receiver and transmitter 0.5W/2W
External radio transmitter 5W/25W
Working frequency
410-470MHz
Communication protocol
TrimTalk450s, TrimMark3, PCC EOT, SOUTH
Cellular Mobile Network
WCDMA3.5G network communication module, GPRS/EDGE compatible, CDMA2000/EVDO
3G optional
Double Module
BLE 4.0 standard, support for android, ios cellphoon connection
+ EDR standard
NFC communication
Realizing close range ( shorter than 10cm ) automatic pair between Galxy G1 and controller
(controller equipped NFC wireless communication module needed)
Data storage/Transmission
4GB internal storage, more than 3 year raw observation data (1.4M/day) base on recording from 14 satelites Plug and play more of
USB data transmission
Data Format
Differential data format: CMR+, CMRx, RTCM2.1, RTCM2.3, RTCM3.0, RTCM3.1, RTCM3.2
GPS output data format: NMEA0813, PJK plan, cordinates binary code
Network model support: various, FKP, MAC, supporting NTRIP protocol
Intertial Sensing System
Tilt survey
Built-in tilt compensator, correcting coordinates automaticlly according to the tilt direction and angle of the centering rod
Electornic Bubble
Conteroller software display electronic bubble, checking leveling status of the centering rod real time
User Interaction
Buttons
One-button operation, Visual operation, convenient and efficient
