Tuya NVR Kits 3MP 4CH 10.1 Inch Monitor CCTV Camera Security System Kit nvr kit 4 cameras
- Category: Surveillance Systems >>>
- Supplier: Guangzhou,Anpaier,Electronics,Co.,Ltd.
Share on:
Product Overview
Description
Model No.: | AP-617824 | |||
APP | Tuya Smart | |||
WiFi NVR Specification | ||||
System | Main processor | XM8516D | ||
screen | 10.1 inch 1280*800 | |||
Operating System | Embedded Linux | |||
System resources | Simultaneous multi-channel real-time recording, playback, network operation, USB backup | |||
Interface | Operator interface | 16-bit true color graphic menu operation interface, support mouse operation | ||
Preview | 1/4 | |||
Video input (IP) | 4*3MP | |||
Access bandwidth | 24Mbps | |||
Forwarding bandwidth | 24Mbps | |||
Video compression | H.265+ | |||
Display quality | Max 3MP | |||
Playback quality | 3MP | |||
Decode | 4*3MP | |||
VR | Unsupport | |||
Motion detection | Support(depend on camera) | |||
Audio | Audio compression | G.711A | ||
Intercom | Support | |||
Record & playback | Recording mode | Manual>Alarm>Dynamic Detection>Timing | ||
Local payback | 4*3MP | |||
Search mode | Search by Time/Calendar/Event/Channel | |||
Record storage | HDD、Network,SD card | |||
Backup mode | Network backup, USB hard disk, USB burner, | |||
External | Video output | 1ch HDMI HD output | ||
Interface | Audio I/O | 0/0 | ||
Alarm I/O | 0/0 | |||
Network interface | 1*RJ45 10M/100M Adaptive Ethernet port+4ch WIFI | |||
USB interface | 2*USB2.0 ports | |||
HDD | 1* SATA+1 SD card | |||
ESATA | No | |||
Serial interface | No | |||
Other | ONVIF | No | ||
Power supply | 5V/2A Type-C | |||
Power Consumption | <10W(Without HDD) | |||
WiFi Camera Specification | ||||
To configure | Processor + sensor | XM530 Ai+2.0M 1/3"Q03 CMOS sensor | ||
Low illumination | Color: 0.1 Lux; B/W: 0.01 Lux | |||
Effective pixel | HD 3MP | |||
Lens | HD lens 3.6MM | |||
Infrared lamp | 8pcs X ￠5 Lamp beads | |||
Infrared distance | 150~200m | |||
Day&night | IR cut filter with auto switch | |||
General | setting | Saturation, brightness and contrast | ||
Adjustable through IE browser or client software. | ||||
Video compression | H.265+ | |||
temperature | -10℃-＋60℃ | |||
humidity | 10%-90% RH | |||
Power supply | DC12V 1A | |||
Consumption | MAX 6W | |||
Waterproof grade | IP66 | |||
Dimension | 221*120*92 | |||
Weight | 0.5 kg | |||
