Audio terminal block connector 3.5mm 3.81mm Pluggable Terminal Block Connector
- Category: >>>
- Supplier: Cixi Zhongheng Electronics Co. Ltd.
Share on (1600560201301):
Product Overview
Description
Pitch:3.50MM/3.81MM | ||
Part | Material | Plated |
Frame: | PA66 UL94V-0 | － |
Wire guard: | Phosphor bronze | Ni |
Screw: | M2.0Steel | Ni |
Clamp: | Brass | Ni |
Electrical | ||
Voltage: | 300V | |
Current: | 10A | |
Wire size: | 16-28AWG | |
Poles: | 2-24P | |
Insulation Reslistance: | 5000MΩ/1000V | |
Withstand Voltage: | AC2000V/1Min | |
Mechanical | ||
Acceptable Temperation: | -33℃~+120℃ | |
Max Soldering: | +250℃,5Sec | |
Strip Length: | 7.0-8.0mm |
