Descriptions:
Kiosk Features:
1. Elegant design, smart operation.
2. Touch screen technology, easy operation friendly interface.
3. Industry PC host, sensitive response, fast processing speed.
4. Mutiple Payment terms solution
5, toughened hard Panel Surface
6,OEM ODM Customized Service
Product Series: | Self Payment Kiosk | Model No: | CK-FTP2301 |
Components | Specifications | ||
Industrial CPU | X86 J1900, 4G+64G | ||
OS Supported | Win7,Win8, Win10 | ||
LCD display | 23inch TFT- LED backlight | ||
Touch screen | 23inch Capacitive multi touch Screen | ||
Resolution | 1920*1080 | ||
View Angle | 178/178 | ||
Brightness | 250cd/m² (250-1000 Optional) | ||
POS Machine | Support bank cards including magnetic card and IC card | ||
Barcode Scanner | Laser scan barcode multiple line and multi-direction technology | ||
Receipt printer | Thermal, 80mm, out of paper with alarm function. auto cutter. | ||
Camera | Optional | ||
Power Supply | 100-240 V AC, 50-60 Hz | ||
Dimension | 555mm(L)*355mm(W)*1325mm(H) | ||
Net weight | 95KG | ||
Kiosk Cabinet | Durable cold rolled steel, high&Low temperature resistance, slim and smart design, easy to install, Moisture proof, Antirust, Anti-acid, Anti-dust, Static free | ||
Custom Option | The above configuration can be customized |
1. Q: Do you accept OEM service?
A: Yes,We can do OEM&ODM service and can customize products according to the drawings you supply.
2. Q: What about the delivery time?
A: Generally, the sample order is 7 to 15 days. While for OEM order or that with special requirement on configuration, then the leading time is 15-20 working days after all order details confirmed.
3. Q: How could I get samples?
A: Free sample is not available. If you need to order sample for checking-up, then both the sample and shipping cost should be charged by you, we will deliver them to you after receiving your payment.
4. Q: What's your payment term?
A: We always accept T/T and West Union payment with FOB, CIF or EXW price.
5. Q: What kind of delivery method you always choose?
A: DHL/FedEx/UPS/EMS is accepted, and it is better if you have your own freight agency.For mass order, we will choose ship by sea.
6. Q: What's the after-sales service you can supply?
A: Be free of 1 year warranty and lifetime maintenance service.Any problems about the product we will give you professional response within 24 hours.
7. Q: What's the MOQ of your products?
A: We have no limit for MOQ, so you can even buy only 1 piece.
