Price:$4,150.00 - $4,500.00
Price in USD:Details

Quantity:


Product Overview

Description



Product Description







Physical Properties
Size:133 mm*87.6 mm
Weight:0.8 Kg (including battery)
Material:magnesium alloy
Operating temperature:-45℃~+75℃
Storage temperature:-55℃~+85℃













          Data Output
Differential data:RTCM2.X、RTCM3.X
Positioning data:NMEA-0183
Static data:HCN、RINEX 2.11





Recommend Products




Details Images










Specification


Satellites and Accuracy [1]
satellite system
GPS+BDS+Glonass+Galileo+QZSS，Support Beidou three generations, support five-star twenty-one frequency point
number of channels
1408
Initialize reliability
99.90%
No network continued test
support
Anti-interference
Built-in multi-frequency anti-jamming technology, effectively improve the fixed effect in harsh environments
RTK accuracy
Plane Accuracy:±( 8mm + 1×10-6×D)mm
Elevation accuracy:±(15mm + 1×10-6×D)mm
static precision
Plane Accuracy:±(2.5mm + 0.5×10-6×D)mm
Elevation accuracy:±( 5mm + 0.5×10-6×D)mm
GNSGNSS+Inertial Navigation【2】
IMU update rate
200Hz
slope
0-60 degrees
Tilt compensation accuracy
10 mm + 0.7 mm/° tilt (accuracy <2.5cm within 30°)
super inertial navigation
Support inertial navigation will not exit after initialization is complete
User interaction
indicator light
1 satellite light + 1 differential data light + 1 static indicator light + 1 power light
button
Static toggle key + power/confirm key
web page
Support PC/mobile web pages
voice
Support handbook voice broadcast
Camera
Features
Support visual stakeout
pixel
2MP
frame rate
25Hz
Field of View (H, V)
75°，75°
Illumination
Starlight-level camera, still maintains full-color picture under 0.01lux illumination
physical properties
size
Φ133 mm*87.6 mm
weight
0.8 Kg (including battery)
material
magnesium alloy
Operating temperature
-45℃~+75℃
storage temperature
-55℃~+85℃
Waterproof and dustproof
IP68 (Protection against 1 meter immersion in water for 30 minutes)
anti-collision
IK08 (with the same mechanical impact force as a 2.5kg steel ram without damage, 3 meters drop resistance)
Electrical properties
Battery
Built-in 6600mAh lithium battery
The typical battery life of the mobile station is more than 16h
fast charge
Support fast charging, charging for 1 hour, typical battery life in visual stakeout mode is 7 hours
External power supply
（5-12）V DC
storage
8GB
data output
Differential data
RTCM2.X、RTCM3.X、CMR、CHC516
positioning data
NMEA-0183
static data
HCN、RINEX 2.11、RINEX3.02
data communication
Wireless connections
Support Wi-Fi data link
network module
Handbook supports 4G full Netcom
radio
Built-in single-receiver radio, support CTI/TT450/transparent transmission protocol
Advanced Features
Online upgrade
Support remote push receiver upgrade
One-click fix
Comes with a CORS account, which can be fixed at startup
Smart service
Support CTI cloud service, provide cloud storage, function code sharing
control handbook
model
iD3
The internet
4G full Netcom, built-in eSIM for three years of surveying and mapping traffic
operating system
Android 10
CPU
Octa-core 2.0GHz
RAM+ROM
3GB+32GB
LCD screen
5.5'' HD display
physical buttons
Full-function keys, support measurement shortcut keys
camera
1300w
Battery
Typical battery life of 14 hours
Waterproof and dustproof
IP68
