Hioso Carrier Level Ethernet Switch 48 GE TX ports, 4 10GE/GE SFP ports Switch layer 2 managed network fiber 48port switch
- Category: >>>
- Supplier: HiOSO Technology Co. Ltd.
Share on (1600562481137):
Product Overview
Description
Product Description
OVERVIEW
FOWAY5000-52TXFSM is a new-generation intelligent 10GE aggregation level switch designed for carrier's IP MAN and enterprise networks. Based on the new-generation high- performance hardware and BDROS platform, it supports functions Such as ACL, QinQ and QoS. Its simple management mode and flexible installation can meet the requirement of any complicated scenarios.
Supports the carrier-level Ethernet- ring protection protocol with less than 50ms recovery time, STP/RSTP/MSTP, backup uplink ports, and LACP link aggregation to cater to the requirements of high reliability of carriers;
Has powerful ACL functions to access and control L2-L7 data based on physical port, providing carriers flexible and various policy control methods;
supports In-Service Software Upgrade (ISSU) to ensure the unremitting data forwarding during system upgrade;
Supports various L2 multicast functions such as IGMP-snooping, fast-leave and MVR to fully meet the operation requirements of carrier’s IPTV.
Supports the carrier-level Ethernet- ring protection protocol with less than 50ms recovery time, STP/RSTP/MSTP, backup uplink ports, and LACP link aggregation to cater to the requirements of high reliability of carriers;
Has powerful ACL functions to access and control L2-L7 data based on physical port, providing carriers flexible and various policy control methods;
supports In-Service Software Upgrade (ISSU) to ensure the unremitting data forwarding during system upgrade;
Supports various L2 multicast functions such as IGMP-snooping, fast-leave and MVR to fully meet the operation requirements of carrier’s IPTV.
Item | FOWAY5000-52TXFSM |
Interface | 48 GE TX ports, 4 GE/10GE SFP+ ports |
Console | 1 RJ45 port |
Backplane | 176Gbps |
Forwarding rate | 132Mbps |
Chassis | Dimensions(W*D*H)mm 440*280*44 |
Weight（KG)empty 3.8 | |
Package | Dimensions(W*D*H)mm 576*448*94 |
Weight（KG)empty 5 | |
Power Consumption | no load <22W |
full load <40W | |
Power supply | AC: 100-240V |
POE power budget | N/A |
Total output BTU | (1000BTU/H=293W) 255.97 |
Fan number | 2 |
Noise@25°C(dBA) | 45 |
MTBF(H) | > 50,000 |
Forwarding mode | Store-forward |
Flash (MB) | 16 |
DRAM (MB) | 256 |
MAC | 32K |
Buffer size(MB) | 4 |
Jumbo frame | 9K |
Total SVI | 10 |
FOWAY5000-52TXFSM | 1 console port, 48 GE TX ports, 4 10GE/GE SFP+ ports; 1 standard AC220V power supply, the cooling fan, 1U, standard 19- inch rack-mounted installation |
