Product Overview
Description
Specification
item | value |
Place of Origin | China |
Jiangsu | |
Brand Name | TOPONE |
Model Number | TO-322 |
Product Name | Door Closer |
Material | Heavy gauge steel or 304 stainless steel |
Certification | CE |
Color | Silver,customized |
Suitable Door Type | Wooden Door,metal doors |
Suitable for | Fire protection,smoke ventilation |
Product Description
Apply to door for fire protection , smoke ventilation.
Endurance test , over 500000 times still keep good performance .
Conforming to U.L.10C and ANSI / BHMA A156.3 - (2008) Grade 1.
In terms of color , silver painted or stainless steel as a standard , could be customized .
Surface mounted for ease of installation.
Specification:
· The max width of door is 1000-1700mm, suitable for the door weight of 80-110kg
` No anchor point of 180°
· Distance: 229mm*19mm
Technological Data | ||
Maximum Width Door Leaf | 1050mm | |
Available Bearing Weight | 80-120KG | |
Types of Rocking Arm | 360° adjustable | |
Speed governing Control | Two stage adjustable speed | |
Maximum Opening Angle | 90° | |
Orienting Function | None Hold Open Only | |
Life Time | ＞500, 000 times | |
INSTALLATION:
Features And Function:
` Install the pivot and rocker on door frame and door edge repectively
` Dig a proper groove in the floor and put the door hinge in it
*Note: Keep the axes of floor hinge and pivot at a line
` Before installing door, fox the panel A on the floor hinge and cover the pivot cap
` Adjust the screw while installing the door to fix the upper pivor well with the pivot of door hinge
` Adjust screw C and screw D to adjust the gap between door and frame
` Adjust screw E and screw F until the door is at closed positin
` Fix panel B
Company Profile
We are established in 1980. Under the principle of bringing forth new ideas constantly, we have developed a series of "TOP ONE"brand door locksets products. We have been producing the door lockset products in Taiwan for more than 20 years and acquired ISO 9001 approval on the product quality.
Our major door hardware products include: Door Lockset, Panic Exit Device, Door Closer, Floor Spring (Floor Hinge), and Door Accessory. We have been developing new door lockset products, meet or even exceed the quality of the world-wide famous brands door lockset products. We have acquired UL certificate and approval in many of our products. Among which, our panic exit device products have passed the grade 1 requirements of the American National Standard Institute and acquired the CE mark of European Union. We are proud of keeping pace with the big door lockset products manufacturers in the facility, quality standard, and R&D technology.
In 1995, we put huge investment in establishing two factories in Shanghai. And in 2017, we moved to Nantong,Jiangsu. Our"TOP ONE" brand products are widely known and accepted in China and the overseas market. We always keep the consistent establishment aim, Quality, Service, Efficiency, and Customer's satisfaction, to win the customer's support, and continue to move forward with the stable concept of running the business.
Our major door hardware products include: Door Lockset, Panic Exit Device, Door Closer, Floor Spring (Floor Hinge), and Door Accessory. We have been developing new door lockset products, meet or even exceed the quality of the world-wide famous brands door lockset products. We have acquired UL certificate and approval in many of our products. Among which, our panic exit device products have passed the grade 1 requirements of the American National Standard Institute and acquired the CE mark of European Union. We are proud of keeping pace with the big door lockset products manufacturers in the facility, quality standard, and R&D technology.
In 1995, we put huge investment in establishing two factories in Shanghai. And in 2017, we moved to Nantong,Jiangsu. Our"TOP ONE" brand products are widely known and accepted in China and the overseas market. We always keep the consistent establishment aim, Quality, Service, Efficiency, and Customer's satisfaction, to win the customer's support, and continue to move forward with the stable concept of running the business.
Application
Certifications
FAQ
Q: Are you trading company or manufacturer ?
A:We are 100% factory.
Q. How can we guarantee quality?
A:Always a pre-production sample before mass production;
Always final Inspection before shipment;
Q.What can you buy from us?
A:Fire exit device,panic evit device,door closer,outside access device,floor hinges
Q. Why should you buy from us not from other suppliers?
A:We have been producing the door lockset products in Taiwan for more than 30 years and developed a series of "TOP ONE" brand door locksets products,acquired ISO 9001 approval on the quality
Factory price ,Fast shipping !
Q. Could you provide free samples?
A Yes we provide free samples and catalog to all the potential clients.
A:We are 100% factory.
Q. How can we guarantee quality?
A:Always a pre-production sample before mass production;
Always final Inspection before shipment;
Q.What can you buy from us?
A:Fire exit device,panic evit device,door closer,outside access device,floor hinges
Q. Why should you buy from us not from other suppliers?
A:We have been producing the door lockset products in Taiwan for more than 30 years and developed a series of "TOP ONE" brand door locksets products,acquired ISO 9001 approval on the quality
Factory price ,Fast shipping !
Q. Could you provide free samples?
A Yes we provide free samples and catalog to all the potential clients.
