Model | SHP 01 | SHP02 | SHP03 | SHP04 | SHP05 | SHP06 | |||||||||||
Cooling capacity | kW | 28.8 | 29.9 | 32.4 | 35.6 | 41.6 | 47.2 | ||||||||||
Heating capacity | kW | 31.1 | 32.3 | 34.6 | 38 | 44.6 | 50.2 | ||||||||||
Power | 380V / 3Ph / 50Hz | ||||||||||||||||
Refrigerating system | 1 | ||||||||||||||||
Refrigerant | R22/R410A/R407C | ||||||||||||||||
Compressor | Quantity | 2 | |||||||||||||||
Condensor | Fan power | 380-420V / 3Ph / 50Hz | |||||||||||||||
Quantity | 1 | 1 | 1 | 2 | 2 | 2 | |||||||||||
Air volume | m3 /h | 12300 | 12300 | 12300 | 14200 | 18800 | 18800 | ||||||||||
evaporator | Centrifugal fan power | 380V / 3Ph / 50Hz | |||||||||||||||
Driving form | belt pulley | ||||||||||||||||
Residual pressure outside the machine(Pa) | 235 | 305 | 290 | 270 | 250 | 290 | |||||||||||
Refrigerant charge(kg) | 7 | 8.2 | 9 | 2x5.3 | 8+4.2 | 9+4.2 | |||||||||||
Dimensions | length | mm | 1940 | 2240 | 2240 | 2540 | 2540 | 2540 | |||||||||
width | mm | 1390 | 1390 | 1390 | 1860 | 1860 | 1860 | ||||||||||
length | mm | 1045 | 1045 | 1045 | 1045 | 1195 | 1195 | ||||||||||
Weight | kg | 460 | 500 | 520 | 650 | 755 | 855 | ||||||||||
