Model | VA-22J | VA-22J-L | VA-40J | VA-40J-L | ||||
Voltage (V / Hz) | 380 / 50 | 380 / 50 | ||||||
Power (kW) / (HP) | 2.2 / 3.0 | 4.0 / 5.5 | ||||||
Starting current (A) | 30 | 60 | ||||||
Rated current (A) | 5.6 | 9 | ||||||
Max air flow (m³/h) / (CFM) | 210 / 123 | 400 / 235 | ||||||
Max vacuum (mmH₂O)/ (kPa) | 2000 / 19.6 | 2100 / 20.5 | ||||||
Noise dB (A) | 74±2 | 75±2 | ||||||
Dia. air inlet (mm) / (in) | Ø 50 / 2 | |||||||
Filter area (m²)/ (sq.ft) | 1.5 / 16.1 | |||||||
Filter efficiency | >99% | |||||||
Capacity of collection barrel (L) / (gal) | 65 / 17.2 | / | 65 / 17.2 | / | ||||
Dimension [L*W*H] (mm) / (in) | 1080*650*1300 / 42.5*25.6*51.2 | 1100*650*1500 / 43.3*25.6*59.1 | 1080*650*1300 / 42.5*25.6*51.2 | 1100*650*1500 / 43.3*25.6*59.1 | ||||
Weight (kg)/(lb) | 90 / 198 | 100 / 220 | ||||||
It is normal that the current value may fluctuate in a small range Voltage and frequency will affect the current value | ||||||||
