Rigging Hardware DIN580 Eye Bolt Carbon Steel Forged Galvanized Lifting Eye Bolt
- Category: >>>
- Supplier: Qingdao Q-Ran Import & Export Co. Ltd.
Share on (1600565323434):
Product Overview
Description
Rigging Hardware DIN580 Eye Bolt Carbon Steel Forged Galvanized Lifting Eye Bolt
Product Description
| Commodity Name | DIN 580 Eye Bolt |
| Type | DIN 580 |
| Process | Drop Forged |
| Surface | Electric Galvanized,Hot Dip Galvanized |
| Size | M6-M100 |
Dimensions for Rigging Hardware Drop Forged Eye Bolt Din580 Small Eye Bolt
| Size | WLL | Dimensions (mm) | Weight | |||||
| d | (tons) | A | B | C | D | E | F | (kgs/100pcs) |
| M6 | 0.08 | 17 | 28 | 16 | 13 | 6 | 17 | 5 |
| M8 | 0.14 | 20 | 36 | 20 | 15 | 6 | 18 | 6 |
| M10 | 0.23 | 25 | 45 | 25 | 18 | 8 | 22 | 11 |
| M12 | 0.34 | 30 | 54 | 30 | 22 | 10 | 26 | 18 |
| M14 | 0.49 | 35 | 63 | 35 | 28 | 12 | 30 | 28 |
| M16 | 0.7 | 35 | 63 | 35 | 28 | 12 | 30 | 28.5 |
| M18 | 0.9 | 35 | 63 | 35 | 28 | 12 | 30 | 45 |
| M20 | 1.2 | 40 | 72 | 40 | 30 | 14 | 35 | 45 |
| M22 | 1.5 | 45 | 81 | 45 | 35 | 16 | 40 | 67 |
| M24 | 1.8 | 50 | 90 | 50 | 38 | 18 | 45 | 87 |
| M27 | 2.5 | 55 | 95 | 53 | 40 | 22 | 50 | 115 |
| M30 | 3.6 | 65 | 108 | 60 | 45 | 22 | 55 | 166 |
| M33 | 4.3 | 65 | 108 | 60 | 45 | 22 | 55 | 172 |
| M36 | 5.1 | 75 | 126 | 70 | 55 | 26 | 65 | 265 |
| M39 | 6.1 | 75 | 126 | 70 | 55 | 26 | 65 | 280 |
| M42 | 7 | 85 | 144 | 80 | 65 | 30 | 75 | 403 |
| M45 | 8 | 85 | 144 | 80 | 65 | 30 | 75 | 425 |
| M48 | 8.6 | 100 | 166 | 90 | 70 | 35 | 85 | 638 |
| M52 | 9.9 | 100 | 166 | 90 | 70 | 35 | 85 | 660 |
| M56 | 11.5 | 110 | 184 | 100 | 80 | 38 | 95 | 880 |
| M64 | 16 | 120 | 206 | 110 | 90 | 42 | 105 | 1240 |
| M72 | 21 | 150 | 260 | 140 | 100 | 60 | 190 | 2330 |
| M80 | 28 | 170 | 296 | 160 | 112 | 70 | 218 | 3420 |
| M100 | 38 | 190 | 330 | 180 | 130 | 75 | 240 | 4910 |
Packaging & Shipping
1.Safety Carton and pallet,sack and pallet,according to customers requirement.
2.Within 30-60 Days on Request.
Technology
Technology of Rigging Hardware Drop Forged Eye Bolt Din580 Small Eye Bolt
Advantages
1.Ourselves factory with strong produce capacity;
2.Supply high quanlity products with lower cost;
3.Our rigging engineers and salesman will supply professional and timely service for customers.
