Standard terminal block 5.00mm control panel terminal block connector 2 pin
Standard terminal block 5.00mm control panel terminal block connector 2 pin
Standard terminal block 5.00mm control panel terminal block connector 2 pin
Standard terminal block 5.00mm control panel terminal block connector 2 pin
Standard terminal block 5.00mm control panel terminal block connector 2 pin
Standard terminal block 5.00mm control panel terminal block connector 2 pin
Standard terminal block 5.00mm control panel terminal block connector 2 pin

Standard terminal block 5.00mm control panel terminal block connector 2 pin

Share on (1600565841157):


Price:

Quantity:


Product Overview

Description







Pitch:5.00MM 5.08MM
Part
Material
Plated
Frame:
PA66 UL94V-0
－
Contact:
Brass
Tin
Electrical
Voltage:
300V
Current:
20A
Wire size:
-
Poles:
2-24P
Insulation Reslistance:
5000MΩ/1000V
Withstand Voltage:
AC2000V/1Min
Mechanical
Acceptable Temperation:
-33℃~+120℃
Max Soldering:
+250℃,5Sec
