W301 2.0 WVTR Permeability Analyzer to test the water vapor transmission rate of films or sheets
WVTR Permeability Analyzer W301 2.0 is designed to test the water vapor transmission rate (WVTR) of films or sheets materials with the principle of Gravimetric Method.
Applied to:
1) Plastic film, composite film, aluminum foil, aluminized film, etc;
2) Sheet, panel, rubber, ceramics, etc;
3) Packaging containers, such as: glass, bottle, cans, boxes, etc;
4) Expanding application: solar panel, LCD film, medical patch, etc.
Widely used in quality inspection organizations, drug control institutions, research institutes, packaging, thin film, food companies, pharmaceutical enterprises, personal care industry, electronics industry and so on.
Standard
GB/T 1037-1988、GB/T 16928-1997、ASTM E96/E96M-2016、ASTM D1653-2013、TAPPI T464、ISO 2528-1995、DIN53122-1、JIS Z0208-1976、YBB00092003-2015
Applied to:
1) Plastic film, composite film, aluminum foil, aluminized film, etc;
2) Sheet, panel, rubber, ceramics, etc;
3) Packaging containers, such as: glass, bottle, cans, boxes, etc;
4) Expanding application: solar panel, LCD film, medical patch, etc.
Widely used in quality inspection organizations, drug control institutions, research institutes, packaging, thin film, food companies, pharmaceutical enterprises, personal care industry, electronics industry and so on.
Standard
GB/T 1037-1988、GB/T 16928-1997、ASTM E96/E96M-2016、ASTM D1653-2013、TAPPI T464、ISO 2528-1995、DIN53122-1、JIS Z0208-1976、YBB00092003-2015
Specification
Technical Specifications | ||
Item | Technical parameters | |
Test range | 0.1~10000 g/m2·24h | |
Test precision | 0.001 g/m2·24h | |
Temperature range | 15~55℃ | |
Temperature accuracy | ±0.1℃ | |
Humidity range | dry method: ≤10%RH | |
Humidity accuracy | ±1%RH | |
Test area | 50.24 cm2 | |
Sample size | Φ90 mm | |
Sample thickness | ≤3mm | |
Number of test sample | 1 piece | |
Power | 450W | |
Power supply | AC 220V，50Hz | |
Company Profile
We GBPI is a professional manufacturer focused on developing
and producing packaging material test instruments. Founded in 2002, the company has received IOS9001 certification and recognized as high-tech enterprise and software enterprise by national authority. We hold numerous technology patents and software certificates from the national authority, and gained awards for technological progress.
and producing packaging material test instruments. Founded in 2002, the company has received IOS9001 certification and recognized as high-tech enterprise and software enterprise by national authority. We hold numerous technology patents and software certificates from the national authority, and gained awards for technological progress.
