Products Description
Static Spray Ball
CIP Spray Ball, Sanitary Rotary Spray Ball for tank cleaning, they are mainly used to clean the inside of tanks for food-processing, beverage, beer and pharmaceutical industries.
• Rotary spray ball: the ball is elliptical or spherical, jet orifice is flat slot shape.
• Fixed spray ball: 360°spray, 180°spray, aperture of spray is 2.5mm.
• Rotary spray ball: the ball is elliptical or spherical, jet orifice is flat slot shape.
• Fixed spray ball: 360°spray, 180°spray, aperture of spray is 2.5mm.
Design Features
● 316L stainless steel, sanitary polished ball
● 360° , 180° up, and 180° down wash patterns
● Various possible spray patterns, materials and surfaces
● Powerful flushing at low pressure
● Orbital welding and directional drilling
● Custom drilling available
TYPICAL APPLICATIONS
● Dairies
● Pharmaceutical processing
● Food and beverage production
● High purity chemical processing
● 316L stainless steel, sanitary polished ball
● 360° , 180° up, and 180° down wash patterns
● Various possible spray patterns, materials and surfaces
● Powerful flushing at low pressure
● Orbital welding and directional drilling
● Custom drilling available
TYPICAL APPLICATIONS
● Dairies
● Pharmaceutical processing
● Food and beverage production
● High purity chemical processing
Sizes available: | 1"-1 1/2" (DN25-DN40) |
Body Material: | AISI 316L/1.4404 |
Seal Material: | Teflon (PTFE) |
Cleaning radius: | 14 meters |
Flow rate: | 4-45m³ |
Inlet pressure: | 58-145psi (4-10 bar), suggest pressure 87 psi (6 bar) |
Max. temperature: | 203°F (95°C) |
