W-SPFA 260℃ PFA Heat shrink tube
˙Applications:
PFA heat shrinkable tubing is made of PFA with excellent high-temperature performance, chemical resistance, high insulation and
excellent mechanical properties. Designed to provide insulation and mechanical protection in severe chemical and thermal
environments. Widely used in electronic, aerospace, military and communication fields. Compared to PTFE tubing, PFA has excellent
clarity.


Materials: PFA˙Operating temperature range:-65℃～260℃
˙Min fully recovery temperature:350℃
* Shrink ratio 1.3:1 and 1.6:1
* Excellent clarity
* High flame resistance
* High temperature resistant to 260℃
* Superior physical and chemical properties.
* RoHS and REACH compliant.


Property
Requirement
Test method
Typical data
Longitudinal shrinkage
≤5%
ASTM D 2671
≤3%
Tensile strength
≥17.3 MPa
ASTM D 2671
≥ 25 MPa
Elongation at break
≥200%
ASTM D 2671
≥300%
Dielectric voltage
withstand
2500V,60sec, no
breakdown
ASTM D 2671
pass
Volume resistivity
≥1015Ω·cm
ASTM D 876
≥1016Ω·cm
Corrosion
No corrosion
ASTM D 2671
No corrosion
Flammability
VW-1
UL224
pass
Dielectric constant


2.1
Friction coefficient


0.1-0.2


Size
ID as supplied
ID After shrinked
Wall after shrinked
1.3:1
φ0.8
0.8
≤0..69
0.20±0.05
φ1.0
1.0
≤0.8
0.20±0.05
φ1.5
1.5
≤1.0
0.20±0.05
Φ1.9
1.9
≤1.20
0.20±0.05
φ2.3
2.3
≤1.60
0.23±0.05
Φ2.9
2.9
≤1.80
0.23±0.05
Φ3.6
3.6
≤2.3
0.23±0.05
φ4.0
4.0
≤2.9
0.25±0.07
φ4.6
4.6
≤3.2
0.25±0.07
φ5.0
5.0
≤3.6
0.25±0.07
Φ5.7
5.7
≤4.0
0.28±0.10
Φ6.4
6.4
≤4.6
0.28±0.10
φ7.4
7.4
≤5.0
0.28±0.10
Φ7.9
7.9
≤5.8
0.28±0.10
Φ9.2
9.2
≤6.4
0.30±0.10
Φ12.7
12.7
≤7.9
0.38±0.10
Φ14.7
14.7
≤9.7
0.50±0.10
Φ16.9
16.9
≤11.4
0.50±0.10
Φ21.1
21.1
≤13.0
0.64±0.10
Φ29.7
29.7
≤16.1
0.90±0.10
Φ33.8
33.8
≤22.7
0.90±0.10
Φ38.1
38.1
≤26.0
0.90±0.10
1.6:1
Φ2.4
2.4
≤1.5
0.20±0.08
Φ3.2
3.2
≤2.0
0.25±0.08
Φ4.8
4.8
≤3.0
0.25±0.08
Φ6.4
6.4
≤4.0
0.25±0.08
Φ9.6
9.6
≤6.0
0.31±0.08
Φ12.7
12.7
≤7.9
0.38±0.10
Φ19.1
19.1
≤11.9
0.51±0.10
Φ25.4
25.4
≤15.9
0.64±0.13
Φ38.1
38.1
≤23.8
0.76±0.13
Other sizes are available upon request
