Satellite Receiver Decoder IRD With CAM BISS Descrambling for Radio & TV Broadcast Equipment
- Category: >>>
- Supplier: Beijing Yukuan Science & Technology Co. Ltd.
Share on (1600566191237):
Product Overview
Description
YUK600-4
Satellite Receiver Decoder IRD With CAM BISS Descrambling for Radio & TV Broadcast Equipment
Product Overview
YUK600-4 receiver supports RF ASI IP input, ASI IP output and 4 carrier RF reception and descrambling. It supports main multiplexing function with dual power hot backup redundancy and web network management.
Product Feature
* Support multiple input RF IP ASI, support DVB-C, DVB-T/T2, DVB-S/S2/S2X
* Four CAM card slots descramble four different signal
* Support multiplexing and demultiplexing function
* Support PID remapping, PCR correction
* CI descrambling supports Conax, NDS, Nagra, Cryptoworks, Irdeto, Mediaguard, Viaccess, and other conditional access systems.Adopt unique digital decoding technology and dual PCMCIA interface, receive various encrypted satellitecable terrestrial digital TV signals by replacing different PCMCIA modules.
* Support BISS-1 and BISS-E decryption
* Friendly user interface and easy-to-operate menu system, all operating functions can be completed on the LCD
* Web network management based on B/S
* Support signal input strength, signal to noise ratio (SNR) dynamic display
Specification
RF Input | ||
RF Input | Support 4 carrier RF reception and descrambling | |
Standard | DVB-C, DVB-T/T2, DVB-S/S2/S2X | |
ASI Input/Output | ||
ASI Input Connector | 2×BNC, 75Ω | |
ASI Output Connector | 2×BNC, 75Ω | |
Executive Standard | DVB-ASI, EN50083-9 | |
Output Bitrate | ≤200Mb/s | |
TS Over IP | ||
Connector | 1×RJ45, 10/100/1000 Base-T | |
Effective Bitrate | 600Mb/s | |
Frame Length | (1-7)×188 adjustable bytes | |
Transfer Protocol | UDP/RTP, Unicast, Multicast | |
Local and Remote Management | ||
Connector | 1×RJ45, 10/100/1000 Base-T | |
Remote Control | HTTP Web | |
Local Control | HTTP Web | |
Equipment Upgrade | IP | |
Physical Specifications | ||
Dimension(L×W×H) | 450mm×350mm×44mm | |
Weight | Net weight 5KG | |
Power | AC 90V～250V，50/60Hz | |
Power Consumption | 24W (excluding LNB power supply) | |
Temperature Range | 0 ~ 45℃(operation), -10 ~ 60℃(storage) | |
Humidity | 10 ~ 90% (Non-condensing) | |
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
