Pressure Sensor Transmitter Transducer dc 5v g1/4 0 1.2 mp for water fuel gas
- Category: >>>
- Supplier: Wuhan Zhenguan Industry And Trade Co. Ltd.
Share on (1600566920563):
Product Overview
Description
Product Description
Technical Parameters
Working Voltage: 5.0 VDC
Output Voltage: 0.5-4.5 VDC
Sensor material: Carbon steel alloy
Working Current: <=10 mA
Working Pressure Range: 0-1.2 MPa
The proof pressure: 1.6 MPa
Destroy Pressure: 2.6 MPa
Working TEMP. Range: -20~105℃ Celsius Degree
Storage Temperature Range: 0-100 Celsius Degree
Measuring Error: +_ 1.5 %FSO
Temperature Range Error: +_0.03 %FSO
Response Time: <=5.0 ms
Cycle Life: 1000000 cycles
1.Suitable for wall hanging furnace, gas furnace, gas storage, etc all kinds of hydraulic, pneumatic pressure measurement
2.Suitable for civil use product batch
3.Static accuracy: plus or minus 1.0% FS
4.Pressure range 0-1.2 MPa (can be customized according to customer requirements)
5.Wide range of temperature compensation
6.Medium for non-corrosive gas, water, oil, etc
company profile
FAQ
| FAQ |
Q: Is there a MOQ for your products?
A: Yes. The MOQ is between 200-1000pcs for different models after sample approval. And it's also okay for us to accept smaller lots for the initial order.
Q: What is the payment?
A: Payment method: TT/ West Union/ Papal/ L/C/ Escrow payment are all available.Payment Way: generally, we accept 30% TT deposit and balance before delivery.After building long and good relationship, better payment way could be negotiated.
Q: What is the lead time?
A: The delivery time is 20-30 days after order be confirmed.But for the exact date, please check with our sales team.
Q: What is your company return policy?
Refund or exchange is promised for defects not damaged by users. You can take photos or video to us for approval first, and then give you a new one during next order.
