BIOBASE China Class II A2 Hepa Filter Biological Safety Cabinet, BSC-1100IIA2-X Biosafety Cabinet for bilogical lab

Share on:


Price:
Price in USD:Details

Quantity:


Product Overview

Description





BIOBASE GROUP adheres to the mission of “SERVICE FOR HEALTH FOR THE FUTURE
We provide with high quality products and best service!


Product Show


1. Motorized front window.
2. Time reserve function.
3. HEPA filter life and UV life indicator.
4. Automatic air speed adjustable with filter block.
5. With memory function in case of power-failure.
6. Audio and visual alarm (Abnormal airflow velocity; Filter replacement; Front window at unsafe height).
7. Work area surrounded by negative pressure, it can ensure maximum safety in work area.
8. Audio and visual alarm (Filter replacement, window over height, abnormal air flow velocity etc).
9. Remote control: all functions can be realized with it, making the operation much easier and more convenient.
10. Interlock function: UV lamp and front window; UV lamp and blower, LED lamp; blower and front window.
11. Foot switch: adjust front window height by foot during experiment, to avoid airflow turbulence caused by arm.




Technical Parameters


Model
BSC-1100IIA2-X
BSC-1300IIA2-X
BSC-1500IIA2-X
BSC-1800IIA2-X
BSC-2000IIA2-X
Internal Size
(W*D*H)
940* 600*660 mm
1150*600*660 mm
1350*600*660
mm
1625*600*660
mm
1800*600*660
mm
External Size
(W*D*H)
1100*750*2250mm
1300*750*2250mm
1500*750*2250
mm
1800*775*2290mm
1950*800*2170
mm
Tested Opening
Safety Height = 200 mm(8'')
Max Opening
420mm(17’’)
420mm(17’’)
500mm(20’’)
550mm(22’’)
400mm(16’’)
Inflow Velocity
0.53±0.025 m/s
Downflow Velocity
0.33±0.025 m/s
ULPA Filter
Two, 99.9995% efficient at 0.12um. Filter life indicator.
Front Window
Motorized. Two-layer laminated toughened glass ≥ 5mm. Anti UV.
Noise
EN12469 ≤ 58 dB / NSF49 ≤ 61 dB
UV Lamp
30W*1
30W* 1
40W* 1
40W*1
40W* 1
UV timer, UV life indicator, emission of 253.7 nanometers
for most efficient decontamination.
Illuminating Lamp
LED Lamp
12W*2
12W*2
16W*2
16W*2
16W*2
Illumination
≥1000Lux
Consumption
760W
800W
900W
900W
1500W
Waterproof Sockets
Two, total load of two sockets: 500W
Display
LCD display: exhaust filter and downflow filter pressure, filter and UV lamp working time, inflow and downflow velocity, filter
life, humidity and temperature, system working time etc.
Control System
Microprocessor
Airflow System
70% air recirculation, 30% air exhaust
Visual and audio alarm
Filter replacement, front window at unsafe height, abnormal airflow velocity.
Material
Work Zone: 304 stainless steel
Main Body: Cold-rolled steel with anti-bacteria powder coating.
Work Surface Height
750mm
Caster
Footmaster caster
Power Supply
AC220V±10%, 50/60Hz; 110V±10%, 60Hz
Standard Accessory
LED lamp, UV lamp*2, Base stand, Remote control, Foot switch, Drain valve, Waterproof sockets*2
Optional Accessory
Water and gas tap, Electric height adjustable base stand.
Gross Weight
243kg
280kg
316kg
395kg
420kg
Package Size
(W*D*H)
1220× 1000× 1840 mm
1460*1050*1800 mm
1630*1000*1820 mm
1930*1000*1820
mm
2090*1050*1860 mm
