  • 1w SMD Chip bi color led diodes UV C LED Diode Disinfection effect
1w SMD Chip bi color led diodes UV C LED Diode Disinfection effect
1w SMD Chip bi-color led diodes UV-C LED Diode Disinfection effect
1w SMD Chip bi-color led diodes UV-C LED Diode Disinfection effect
1w SMD Chip bi-color led diodes UV-C LED Diode Disinfection effect
1w SMD Chip bi-color led diodes UV-C LED Diode Disinfection effect
1w SMD Chip bi-color led diodes UV-C LED Diode Disinfection effect

1w SMD Chip bi color led diodes UV C LED Diode Disinfection effect

Share on (1600567122030):


Price:

Quantity:


Product Overview

Description



Product Description




Forward Current
20mA
Peak Forward Current
50mA
ReverseVoltage
5V
Power Dissipation
60mw
Electrostatic discharge
2000V
Operation Temperature
-30～+80℃
Forward Voltage
R:1.8-2.4
G:2.6-3.4
Wavelength
R:620-630
Y:520-530
Viewing Angle
120deg
Soldering Temperature
Reflow Soldering: 220℃ for 5 sec Hand Soldering: 280℃ for 3 sec


Feature;
1. Chip Material; InGaN/GaAsp
2.Shape; round led, oval led, straw hat led , helmet led , square led flat top led , bullet led, concave led, rectangle led
3.Available Size; 2mm,3mm,5mm,8mm,10mm,20mm
4. Lens type;water clear, color transparent, colored diffuse
5. Emitted color; Red, White, Yellow, Orange, yellow-green, Green, Blue
6. Different angle available
7. Low power consumption, high intensity, uniform illumination
8. Solid-state, high shock and vibration resistant
9. Major reduction in power cost
10. No RF interference
11. Maintenance free, easy installation
12. Long life 100,000+hours
13. Superior ESD protection

Application; Advertising signs, circuit board, computer, monitor, portable equipment, project building, status indicator,
telephone, traffic signal lights and automotive, tv set ,car decoration, channel letter lighting.

1)our product coved range; led emitting diode, dip led, led light diode ,led diode rgb,double color, full color led, tri color led
,led lamp diode, super bright led, high power led, SMD, led strip, led module, led component, piranha. if you need any types of
product, please feel free to contact with us, we are give you best service.






SHENZHEN HANHUA OPTO CP.,LTD

Shenzhen Hanhua Otpo CO., LTD ,a high-tech enterprise,which was founded in 2008 with 11years experience in LED manufacturing with our own factory.It takes an area of 1700㎡ independent workshop in a building. Our main products include SMD LED,DIP LED,high Power LED,which are widely used in auto industry,commercial lighting,traffic light,display,bill board,ect.









FAQ


Q1: Are you a factory?
A: Yes, we have our own factory in Shenzhen. if you have time come China, welcome your visisting!

Q2: Could you please send me the free sample, so that I could see and check its quality?
A: Yes. We can send you free samples first, if the value is low. But our clients should pay for the shipping freight themselves.

Q3: Can you accept OEM and ODM order?
A: Yes. We are able to complete your OEM and ODM orders. We have large quantities of led products in stock for normal models. For special models, it will takes some time to customize them. Samples fee needs to be charged if the value is high.

Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
