DELLEMC DS6505B EM 6505 12 16G 0R Brocade BR 6505 12 16G 0R HD 6505 12 16G 0R FC Switch Storage Area Networking

Product Overview

Description

Brocade BR-6505-12-16G-0R DELL EMC EM-6505-12-16G-0R HD-6505-12-16G-0R FC Switch Storage Area Networking

• 16Gigabit SAN Switch/ FC Switch


• Brand: Brocade/ DELL / EMCHitachi


• Guarantee:100% Brocade original


•


  BR 6505 12P 16Gb SFPS BR AC SGL PSU




  The Brocade 6505 Switch with Gen 5 Fibre Channel provides exceptional price/16 Gbps performance value, combining flexibility, simplicity, and enterprise-class functionality in an entry-level switch. Designed to enable maximum flexibility and reliability, the Brocade 6505 is configurable in 12 or 24 ports and supports 2, 4, 8, or 16 Gbps speeds in an efficiently designed 1U package. It comes standard with a single power supply with integrated fans. A second, optional power supply provides additional redundancy for increased resiliency.




  A simplified deployment process and a point-and-click user interface make the Brocade 6505 both powerful and easy to use. Moreover, the Brocade 6505 offers low-cost access to industry-leading Gen 5 Fibre Channel technology while providing “pay-as-you-grow” scalability to meet the needs of an evolving storage environment.




  Additional highlights include:





  • Provides exceptional price/performance value, combining flexibility, simplicity, and enterprise-class functionality in a 24-port, 1U entry-level switch


  • Enables fast, easy, and cost-effective scaling from 12 to 24 ports using Ports on Demand (PoD) capabilities


  • Simplifies management through Brocade Fabric Vision technology, reducing operational costs and improving application performance


  • Helps maximize application uptime and performance while reducing overall operational expenses with ClearLink Diagnostic Ports (D_Ports)


  • Maximizes resiliency with non-disruptive software upgrades and an optional redundant power supply


  • Simplifies deployment with the Brocade EZSwitchSetup wizard


  • Simplifies server connectivity and SAN scalability by offering dual functionality as either a full-fabric SAN switch or an NPIV-enabled Brocade Access Gateway






•













































  Main features	Systems Architecture
  Power consumption	80 W with all 24 ports populated with 16 Gbps SWL optics 60 W for empty chassis with no optics
  Scalability	Full-fabric architecture with a maximum of 239 switches
  Certified maximum	6000 active nodes; 56 switches, 19 hops in Brocade Fabric OS® fabrics; larger fabrics certified as required
  Management access	10/100 Mbps Ethernet (RJ-45), in-band over Fibre Channel, serial port (RJ-45), and one USB port
  ISL Trunking	Frame-based Trunking with up to eight 16 Gbps ports per ISL trunk; up to 128 Gbps per ISL trunk. Exchange-based load balancing across ISLs with DPS included in Brocade Fabric OS.
  USB	One USB port for system log file downloads or firmware upgrades
  Vibration	Operating: 0.5 g sine, 0.4 grms random, 5 Hz to 500 Hz Non-operating: 2.0 g sine, 1.1 grms random, 5 Hz to 500 Hz
  Power supply	Base switch includes a single, hot-swappable power supply with integrated system cooling fans. Optional dual redundant hot-swappable power supply.
