Бульдозер с лесозаготовкой марки Yishan T180F, л.с.
- Category: Bulldozers >>>
- Supplier: Oriemac Machinery & Equipment (Shanghai) Co. Ltd.
Share on (1600568153136):
Product Overview
Description
Company Video
Product Description
Specification
YISHAN T180F Log Bulldozer
01.WEICHAI 180hp engine
02. 610mm track shoe
03. Angle blade 3970×1050mm 4.3cbm
04. with winch
05. 6260*3970*3063mm
Winch details:
Weight: 1390kg
Bare drum cable line pull: 266.8 Kn
dull drum cable line pull: 157.7 Kn
wire diameter x length: 26*6600mm
Blade type | Straight tilt | Angle | U-blade |
Operating weight (kg) | 17900 | 18200 | 18500 |
Min. Ground clearance (mm) | 400 | 400 | 400 |
Min. Turning radius (mm) | 3300 | 3300 | 3300 |
Ground pressure (Mpa) | 0.065 | 0.066 | 0.066 |
Track gauge (mm) | 1880 | 1880 | 1880 |
Max. pulling force (KN) | 147.2 | 147.2 | 147.2 |
Grade ability (0) | 30 | 30 | 30 |
Blade capacity (m3) | 4.5 | 4.3 | 8.6 |
Blade dimension (W X H mm) | 3416 X 1149 | 3970 X 1050 | 4164 X 1386 |
Max. lift (mm) | 1124 | 1250 | 1250 |
Max. depth (mm) | 584 | 545 | 545 |
Max. Tilt adjustment (mm) | ≥860 | ≥400 | ≥400 |
Pitch adjustment ( 0) | 55 | 55 | 55 |
Capacity (theoretical value-40m: m3/h) | 297.4 | 297.4 | 297.4 |
Weight of the blade (kg) | 2218 | 2015 | 2223 |
