4 Axis Cnc Index Rotary Table Ordinary Product Dividing Head MD 170A for Cnc Universal Milling Machine Steel
- Category: >>>
- Supplier: Dongguan Mihong Mechanical Hardware Co. Ltd.
Share on (1600568639654):
Product Overview
Description
Product Overview
4 Axis Cnc Index Rotary Table Ordinary Product Dividing Head MD-170A for
Cnc Universal Milling Machine Steel
This cnc rotary table used dual lead worm &gear to ensure the rotary table accuracy
FEATURES AT A GLANCE
Right elevation
Left elevation
Front elevation
PRODUCT SPECIFICATIONS
Model | MD-170 |
Disc diameter | 170 |
Disc spindle center hole | 50h7 |
Disc spindle center through hole | 45 |
Level placement height | 221mm |
Vertical placement center height | 135mm |
Rotate axis disc T slot width | 12h7 |
Guide block width | 14h7 |
Locking force | 5kg/cm² pneumatic (25 kg/cm² hydraulic) |
Mini equal division angle | 0.001 degree |
Weight | 60kg |
PRODUCT CONFIGURATION
CHANGCHAI high power engine
Imported EATON control valve
Japan Shimadzu hydraulic motor
SALES AND SERVICE NETWORK
Successful Project
Fanuc system
Brother system
Hass system
SIMILAR PRODUCTS
FAQ
Q1: How long does the delivery time for the cnc rotary table ?
A1:We have 4th axis cnc rotary table in stock ,the 5th axis rotary table need
more than 7 days.
Q2:Which system suit for the cnc rotary table ?
A2: Fanuc ,Mitsubishi,siemens,Haas, GSK,Syntec etc .
more than 7 days.
Q2:Which system suit for the cnc rotary table ?
A2: Fanuc ,Mitsubishi,siemens,Haas, GSK,Syntec etc .
