Integrated Long Range UHF RFID Reader for Non Stop Parking System

RFID Reader is based on the most advanced reader technology in the world combined ,with the characteristics of optical excitation and precise positioning, and developing-distance card reading device for parking lots application only.

Product working principle

The car equipped with the remote card reader passes through the infrared scanning area of the card reader( when the scanning angle is 45 degrees), and the sleeping long distance card receives the infrared activation signal of the card reader and is awakened to work. The radio frequency electromagnetic wave is used to transmit the information to the card reader, and the card reader verifies the received information, performs decoding and verification, and the data is matched and uploaded to the upper computer.

Installation requirements

Installation angle:

As shown in the figure. The angle between the card reader and the pole is about 30 degrees, and the front of the card reader is tilted by about 30 degrees toward the road surface where the car enters.

Wiring requirements

Wiring between card reader and controller:

(1) Wiegand interface controller: The card reader and the controller are connected by 5-core wires with a wire diameter of not less than 0.5 mm 2 and a length of less than 200 m, two power supplies and three Wiegand signal lines.

(2) 485 interface controller : the card reader and the controller are connected by a 2-core twisted pair cable with a wire diameter of not less than 0.5 mm 2 and a length of less than 1000 m

(3) Power supply:12V/3A,use high quality linear power supply

Field installation card distance test

After installing the device as required, please turn on the power of the card reader: install the remote card to the rear view mirror of the car windshield, and drive the card to wake up in the direction of the card reader. Adjust the card reader reading direction as needed to achieve the best results.

1. Technical Solution Innovation

The other brand rfid card on the market usually has a battery life about 6 months, and some better one can be used for about 12 months.

But the rfid card produced by JUTAI, the entire design concept is completely from the perspective of low power consumption.
With conventional rfid cards, our battery life can be used longer than one and a half years. The ultra-low power consumption card designed by JUTAI can have a super long battery using life,which can be used  at least 2.5 years. (Battery model CR2032, brand: Panasonic, one card with 2 Battery as standard);

2. JUTAI Card Very Hard To Copy

The other brand rfid card on the market has low chip cost and low encryption level.

JUTAI rfid card adopts a high-level encryption technology, so JUTAI rfid Cards is more difficult to copy ,so our rfid cards can improves the security level of the entire community. And In addition, property companies can easily make a profit.

3. Comprehensive cost-effective

After many years of technological precipitation and accumulation,JUTAI have very rich experience in the radio frequency field. We do R & D and production of all series of stable and reliable long-distance rfid reader. And sell to foreign country Wholesalers or projects intergrator directly,  so we can have an absolute advantage in cost.

4. Production Line Extension

JUTAI not only designs a series of long-distance card readers, but we are also expanding the cloud access control system in depth, which can provide customers with a series of complete hardware and software solutions, and further expand product encryption technology to ensure maximum security, To prevent random copying of cards and protect customers' economic interests.

4. Can Penetrate VKOOL Explosion-Proof Membrane

We use a car with VKOOL metal explosion-proof film for card reading test. The card is placed in the car, the window is closed, the car is quickly driven, and the JUTAI  card reader can quickly read the card in a range of about 10 meters. After the card number is collected by JUTAI rfid reader, it will be quickly detected and processed, and the card number will be quickly transmitted to the control board, so car can go though barrier gate with fast speed but without stopping car.

5. Can Detect Fast Speed Car

The JUTAI rfid card reader uses a unique chip control program, so it has a very fast response capability. When the car passes the reader at a speed of 60 km / h, our reader can respond quickly and collect the card information, Thereby opening the barrier and improving the overall comfort feeling.

6. Rainy Day Application, Avoid being wet by rain, Reduce the risk of theft

Many countries in Southeast Asia have a lot of thunderstorms. For traditional short distance cards, you need to stop the car, roll down the window, and stick out your hand to read the card. This way, our clothes are easily wet, and in addition, if we shake the window, we may be caught by people. These unsafe hidden dangers, JUTAI  card reader can easily solve.
