Model | WTZY-1685 | WTZY-1688 | WTZY-120 | WTZY-150 |
Packing size | 1700*1300*1600mm | 2030*890*1920mm | 2180*960*1820mm | 2200*1460*1750mm |
Packing weight | 620 KG | 930 KG | 1020 KG | 1560KG |
Power | 380v 50hz three phase | 380v 50hz three phase | 380v 50hz three phase | 380v 50hz three phase |
Diameter of Squeezing Worms | 80mm | Ø100mm | Ø120mm | ø148mm |
Speed of Squeezing Worms | 60r/min | 40r/min | 36r/min | 36r/min |
Diameter of Internal Circle of Pressing Chest | 82mm | Ø102mm | Ø122mm | ø150mm |
Main Engine Configuration Power | 6-7.5kw | 6-7.5kw | 6-11kw | 22kw |
Heater | 3kw | 3.5kw | 4kw | 5kw |
Handling Capacity | 80-160kg/h | 150-260kg/h | 260-400kg/h | 400-500kg/h |
