Hospital Medical Surgical Emergency Equipment Portable ICU Multiparameter Patient Monitors Vital Sign Monitoring
- Category: >>>
- Supplier: Beijing Hongrunda Sci-Tech Development Co. Ltd.
Share on (1600570200643):
Product Overview
Description
Product Parameter
Mutiparameter Patient Monitor
Certificate: CE，CFDA，RHOS，ISO13485
Features：
1. High blood oxygen saturation detection sensitivity, fully supports weak pulse detection
2. Applicable to different groups of people: adults, children, newborns
3. Quickly set the alarm function, support network connection, and set up a monitoring network system
Features：
1. High blood oxygen saturation detection sensitivity, fully supports weak pulse detection
2. Applicable to different groups of people: adults, children, newborns
3. Quickly set the alarm function, support network connection, and set up a monitoring network system
4. Optional extend parameter configuration: end-tidal carbon dioxide;
5. Optional configuration: handle, monitor stand cart or wall stand, optional touch screen
Specification | ||
Parameters | ECG, HP, RESP, SPO2, NIBP,TEMP | |
Product Size | 210*85*180mm N.W.：1.35kg | |
Packing Size | 263*255*190mm N.W.：3.4kg | |
Apply For | Adult/Pediatric/Neonatal | |
Application | Medicine/Surgery/Operating Room/ICU/CCU | |
Display | 8.4 inch LCD Screen | |
Operating Environment | ||
Temperature: | 0 ~ 40 ℃ | |
Humidity: | ≦85% | |
Pressure: | 86.0 kPa ~ 106.0kPa | |
Transport and Storage environment : | ||
Temperature: | -20 ~ 55 ℃ | |
Humidity: | ≦93% | |
Pressure: | 86.0 kPa~ 106.0kPa | |
Power Requirements | ||
AC: | 100 ~ 240V, 50Hz/60Hz | |
DC: | Built-in rechargeable battery | |
Battery: | 11.1V 24wh Li-ion battery; 2h operating after full charge; 5min operating after low battery alarm; | |
Date Storage | ||
Trend diagram/table: | 720h | |
NIBP review: | 10000 events | |
Wave review: | 12h | |
Alarm review: | 200 alarm events | |
Analysis: | Support drug concentration titration analysis | |
ECG | ||
5 Leads: | RA, LA, LL, RL, V | |
Lead mode: | I, Ⅱ, Ⅲ, AVR, AVL, AVF, V | |
Gain: | × 1.25mm/mV,2.5mm/mV, 5.0mm/mV,10mm/mV, 20mm/mV (error ≤ 5%) | |
Sweep speed: | 6.25mm/s,12.5mm/s,25mm/s, 50mm/s (error ≤ ± 10%) | |
Bandwidth: | Surgery 1 ~ 25 Hz, Monitor 0.5 ~ 40 Hz, Diagnostic 0.05 ~ 130 Hz | |
Sensitivity: | >200 u V P-P | |
CMRR: | ≥ 112dB | |
Differential Input Impedance: | >5M | |
ohm Electrode Offset Potential: | ±300mV | |
Polarization Voltage: | ≥ ± 500mV | |
Input Impedance: | ≥ 5 M | |
Calibration Voltage: | 1mV ± 5% | |
ST Segment | ||
ST Segment Range: | -2.0mV ~ +2.0mV | |
Accuracy: | 0.02mV | |
Optional accessories | 1.Trolley bracket | |
2.Hanging bracket | ||
3.Monitor recorder | ||
4.Vehicle-mounted power supply | ||
If you need more product parameter,please send an inquiry to us~ | ||
Details Images
Certifications
Company Profile
Beijing Hongrunda (HRD) Sci-Tech Development Co., Ltd Was Established in Beijing Since 1997, which is the TOP 10 Manufacturer of Anesthesia Machine And Ventilator in China. As the Experts in Medical Field, we have rich experience in production and maintenance, we warlmly welcome you to be our Agent.
Our company produce products in Beijing factory and sells products through all over the world. All our products have been examined and proved by ISO and CE. The quality has reached the top level among the same kind of products in China. We have many representative offices in different kind of Chinese province for advertising, sales, technical support and customer services. We keep very close contact with hundreds of hospitals and thousands of doctors through all over the world. We offer our customers one-year free warranty, lifelong maintenance, technical consultation and operator and sales training.
We welcome you to contact us or Concult Technical Problems. We have been adhering to the belief of making a contribution to human health and devoting ourselves to the medical industry. Believe we can do well together!
Exhibition
Factory Photo
Product packaging
FAQ
Q1:Are You A Manufacturer Or Trading Company?
A1:We Are The Top 10 Manufacturer of ICU Equipment in China Since 1997.
Q2:Do You Need Foreign Agent?
A2:Surely Yes, We Warmly Welcome Foreign Clients To Be our Agent.
Q3:How Can We Guarantee Guality?
A3: Each Production Step Has Two Times Inspection, Engineers Simulating Actual Operation Of Each Machine Before Shipping.
Q4:Why Should We Buy From You Rather than from other suppliers?
A4: Producing Stable Quality And Affordable Products Is Our Purpose! HRD have been producing medical devices for more than 24 years, we have rich experience in production and maintenance.
Q5:What’s your lead time?
A5:2-3 days for sample orders. 7-20 days for mass production(Negotiable)
A1:We Are The Top 10 Manufacturer of ICU Equipment in China Since 1997.
Q2:Do You Need Foreign Agent?
A2:Surely Yes, We Warmly Welcome Foreign Clients To Be our Agent.
Q3:How Can We Guarantee Guality?
A3: Each Production Step Has Two Times Inspection, Engineers Simulating Actual Operation Of Each Machine Before Shipping.
Q4:Why Should We Buy From You Rather than from other suppliers?
A4: Producing Stable Quality And Affordable Products Is Our Purpose! HRD have been producing medical devices for more than 24 years, we have rich experience in production and maintenance.
Q5:What’s your lead time?
A5:2-3 days for sample orders. 7-20 days for mass production(Negotiable)
