DALIAN CHINA CK5120 CK5123 single column conventional vertical lathe machine for heavy cutting
DALIAN CHINA CK5120 CK5123 single column conventional vertical lathe machine for heavy cutting
DALIAN CHINA CK5120 CK5123 single column conventional vertical lathe machine for heavy cutting
DALIAN CHINA CK5120 CK5123 single column conventional vertical lathe machine for heavy cutting
DALIAN CHINA CK5120 CK5123 single column conventional vertical lathe machine for heavy cutting

DALIAN CHINA CK5120 CK5123 single column conventional vertical lathe machine for heavy cutting

Share on (1600570215598):


Price:$50,000.00

Quantity:


Product Overview

Description



BASIC SPECIFICATION
UNIT
CK5112
CK5116
CK5120
CK5123
CK5126
MAX TURNING DIAMETER
MM
1250
1600
2000
2300
2600
DIAMETER OF WORKTABLE
MM
1000
1400
1800
2000
2250
MAX. WEIGHT OF WORKTABLE
TON
3.5
5
8
8
10
MAX. HEIGHT OF WORKTABLE
MM
1000
1200
1400
1400
1600
SPEED STEP OF WORKTABLE TURNING
STEP
4 steps with frequency conversion
TOOLPOST
Square ram with square toolpost/4 position electric turret
MAX. CUTTING FORCE OF TOOL POST
N.
17000
25000
40000
40000
50000
SPEED RANG OF WORKTABLE TURNING
R/MIN
2-250
2-200
2-120
2-120
2-80
TOOL POST HORIZONTAL TRAVERSE
MM
850
1020
1115
1400
1500
TOOL POST VERTICAL TRAVERSE
MM
650
800
800
800
1000
RAPID TRAVERSE OF TOOL HEAD
MM/MIN
8000/3000(heavy cuting)
3000
3000
3000
section of tool shank(LXW)
MM
32*32
40*40
40*40
40*40
40*40
POWER OF MAIN MOTOR
KW
37
45
45
45
45
CNC SYSTEM
Siemens/Fanuc
