Low price white granular GPPS plastic particle injection material: Chi Mei GPPS PG33
- Category: >>>
- Supplier: Hangzhou Yuhang Trade Co. Ltd.
Share on (1600570664385):
Product Overview
Description
item | value |
Place of Origin | China |
Brand Name | zhenjiangqimei |
Model Number | PG-33 |
Material status | Circulation is normal |
features | transparent |
Processing method | Injection molding |
form | The particle |
Physical properties of | The test conditions | Attribute values | unit | The test method |
Investment refers to | 200℃ 10kg | 75 | g/10 min | ISO 1133 |
Investment refers to | 200℃ 5kg | 8.0 | g/10 min | ASTM D1238 |
The proportion of | 23℃ | 1.05 | g/cm³ | ASTM D792 |
Mechanical properties of | The test conditions | Attribute values | unit | The test method |
elongation | 2.0 | % | ASTM D790 | |
The tensile strength | 480 | kg/cm² | ASTM D638 | |
The bending strength | 650 | kg/cm² | ASTM D790 | |
Bending modulus | 31000 | 31000 | ASTM D790 | |
Thermal performance | The test conditions | Attribute values | unit | The test method |
Thermal deformation temperature | annealing | 88 | °C | ASTM D648 |
Thermal deformation temperature | Without annealing | 79 | °C | ASTM D648 |
Veka softening point | 94 | °C | ASTM D1525 | |
Impact properties | The test conditions | Attribute values | unit | The test method |
Impact strength of cantilever beam | 1/8" | 1.7 | kg-cm/cm | ASTM D256 |
Impact strength of cantilever beam | 1/4" | 1.6 | kg-cm/cm | ASTM D256 |
hardness | The test conditions | Attribute values | unit | The test method |
Rockwell hardness | 77 | There is no | ASTM D785 |
General-purpose grade polystyrene is a thermoplastic resin, which is colorless, odorless, tasteless and glossy, transparent bead
or granular solid. Density 1.04 ~ 1.09, transparency 88% ~ 92%, refractive index 1.59 ~ 1.60. Under the action of stress,
birefringence occurs, that is, the so-called stress-optical effect. The melting temperature of the product is 150 ~ 180℃, the
thermal decomposition temperature is 300℃, the thermal deformation temperature is 70 ~ 100℃, and the long-term use temperature is
60 ~ 80℃. At 5 ~ 6℃ lower than the hot deformation temperature, after annealing treatment, the stress can be eliminated and the
hot deformation temperature can be increased. The heat resistance of general polystyrene can be improved if a little α-methyl
styrene is added in the production process.
or granular solid. Density 1.04 ~ 1.09, transparency 88% ~ 92%, refractive index 1.59 ~ 1.60. Under the action of stress,
birefringence occurs, that is, the so-called stress-optical effect. The melting temperature of the product is 150 ~ 180℃, the
thermal decomposition temperature is 300℃, the thermal deformation temperature is 70 ~ 100℃, and the long-term use temperature is
60 ~ 80℃. At 5 ~ 6℃ lower than the hot deformation temperature, after annealing treatment, the stress can be eliminated and the
hot deformation temperature can be increased. The heat resistance of general polystyrene can be improved if a little α-methyl
styrene is added in the production process.
It is soluble in aromatic hydrocarbons, chlorinated hydrocarbons, aliphatic ketones and esters, but can only swell in acetone. Can
be resistant to some mineral oil, organic acid, alkali, salt, low alcohol and its aqueous solution. Low water absorption, it can
still maintain its mechanical properties and dimensional stability in wet environment. Its optical properties are second only to
acrylic resins. Excellent electrical performance, volume resistivity and surface resistivity are very high, and is not affected by
temperature, humidity changes, also is not affected by corona discharge. The radiation resistance is also very good. Its main
disadvantage is brittle, low impact strength, poor heat resistance, can not resist boiling water, can only be used at a lower
temperature and a lower load. Light resistance is poor and flammable. Black smoke when burning, and have a special smell.
be resistant to some mineral oil, organic acid, alkali, salt, low alcohol and its aqueous solution. Low water absorption, it can
still maintain its mechanical properties and dimensional stability in wet environment. Its optical properties are second only to
acrylic resins. Excellent electrical performance, volume resistivity and surface resistivity are very high, and is not affected by
temperature, humidity changes, also is not affected by corona discharge. The radiation resistance is also very good. Its main
disadvantage is brittle, low impact strength, poor heat resistance, can not resist boiling water, can only be used at a lower
temperature and a lower load. Light resistance is poor and flammable. Black smoke when burning, and have a special smell.
The application of GPPS
Polystyrene transparent, with excellent rigidity, electrical performance and printing performance, especially health, low price, so that it has broad application prospects in food packaging. In the electromechanical industry, instrumentation, communication equipment and other industries has been widely used in all kinds of instrument shell, lamp shade, optics
Parts, instrument parts, transparent window mirror, transparent model, chemical acid storage tank, acid transport tank, telecommunication parts, high frequency capacitor, high frequency insulation pad, support, buried and frozen insulation materials. Also widely used in a variety of daily articles, such as bottle caps, containers, decorations, buttons, combs,
Toothbrush, soap box, cigarette box and toys.
Parts, instrument parts, transparent window mirror, transparent model, chemical acid storage tank, acid transport tank, telecommunication parts, high frequency capacitor, high frequency insulation pad, support, buried and frozen insulation materials. Also widely used in a variety of daily articles, such as bottle caps, containers, decorations, buttons, combs,
Toothbrush, soap box, cigarette box and toys.
