High quality 8port POE Switch PCB Board POE IN OUT 8*10/100Mbps RJ45 Ports Reverse 63W PoE Switch with 2 Uplink Ports

Share on (1600571390512):


Price:$27.00 - $33.00

Quantity:


Product Overview

Description



Product Description





FOWAY1210P  8 100M POE + 2 100M TP





Overview


HiOSO FOWAY1210P is our nine port PoE Ethernet switch with 8 10/100M RJ45 PoE ports and 2 10/100M RJ45 uplink port. It can be either managed or unmanaged through web/SNMP (optional).





FOWAY1210P supports 8023af 15.4W or IEEE802.3at 30W PoE standard. It automatically discovers and supplies power to the power receiving devices by support IEEE802.3af/at.  switch is capable of identifying if connected devices support PoE and only provide power to those devices support POE.





FOWAY1210P can seamlessly work with and supply power to network devices such as IP camera, IP phone, wireless AP, etc., especially in transmitting HD videos with strict requirements in security, power and traffic system..








Feature


8 10/100M RJ45 PoE ports and 2 100M RJ45 uplink port


Auto discovery of standard power receiving device on every port


Support IEEE802.3af 15.4W and IEEE802.3at 30W PoE standards


Full 100M rate, full-duplex non-blocking forwarding on every pot


2K MAC learning, 1Mbit storage of forward cache space, 2G back plane bandwidth


Anti-high voltage with lightning protection and anti-interference ability on each RJ45 port


External power supply


Metal casing better for heat dissipating














Technical Specification

















































































Parameter



Specification




Standard



IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX Fast Ethernet, IEEE802.3af, IEEE802.3at, IEEE802.1d Spanning Tree




PoE



PoE ports: 8


Standard and power consumption:IEEE802.3af 15.4W, IEEE802.3at 30W


Working mode: auto discovery power receiving devices and auto power supply/power cutting




Distance



100m




Port



8 100M PoE ports: 10/100Mbps


2 uplink port: RJ45 port 10/100M bps













Buffer memory space



MAC



2K



Bit error rate











MTBF



100000 hours




Power



DC48V




Power consumption



5W, PoE power supplying maximum 240W




Working temperature



-10~60℃




Storage temperature



-40~80℃




Humidity



5%~90% non-condensing




Dimension



28mm (H)×193mm(W)×119mm (D)







Order information









































No



Product code



NMS



Ports



PoE ports



1



FOWAY1210P



No



8 100M PoE +2 100M RJ45 uplink



8 PoE ports IEEE802.3af/at 125W



2



FOWAY1210P-240W



No



8 100M PoE +2 100M RJ45 uplink



8 PoE ports IEEE802.3af/at 240W



3



FOWAY1210PM



Yes



8 100M PoE +2 100M RJ45 uplink



8 PoE ports IEEE802.3af/at 125W



4



FOWAY1210PM-240W



Yes



8 100M PoE +2 100M RJ45 uplink



8 PoE ports IEEE802.3af/at 240W
