EDUP PCIE WiFi 6E Card AX210 AX5400M Bluetooth 5.2 Heat Sink Tri Band PCI E Wireless Wi Fi Network Card Adapter for Gaming

Share on:

Price:$8.00 - $18.50
Price in USD:Details


Product Overview


EDUP PCIE WiFi 6E Card AX210 AX5400M Bluetooth 5.2 Heat Sink Tri-Band PCI-E Wireless Wi-Fi Network Card Adapter for Gaming

The similar ax200

        In-tel WiFi6 AX200 Chipset                                AX3000Mbps PCI-E wifi card with AX200AX200-00_.jpg01.jpg

   EP-9636GS AX200 with heat sink                        EP-9651GS AX210 PCI-E network card

04.jpg               06.jpg

Product Description

The EP-9651GS is a highly integrated and cost-effective Wireless Adapter that provides PCI Express interface, and full compliance with IEEE802.11ax and IEEE802.11a/b/g/n/ac standards. Wireless transmission rates can reach up to 3000Mbps. Using the EP-9651GS Wireless Desktop PCI-E Adapter not only can you connect your desktop computer to a high-speed Wi-Fi network and experience faster files transmission and high-speed Internet browsing from further distances across your home than that in previous-generation Wireless n technology, but also you can enjoy high performance wireless viewing HD multimedia and real-time online war game when the PCI-E Adapter work in 11ac 5G mode. This Desktop PCI-E Adapter is the best choice for the desktop computer users who want to enjoy a better wireless performance and high-speed Wi-Fi . the in-tel Wi-Fi 6 AX210 module can provide Gigabit wireless speed2 and dramatically improve your connected experience at home, work, or on the go.




Ø Complies with IEEE 802.11a/b/g/n/ac/ax WiFi and BT 5.2HS (WiFi: PCI-E, BT: USB)

Ø Supports PCI-E-X1/X4/X8/X16

Ø 2.4G/5G dual frequency optional, 5GHz band rate up to 2400Mbps, 2.4GHz band rate up to 574Mbps

Ø Supports Cisco CCX

Ø Supports multiple BSSID

Ø The router need to support AX and use 160Mhz channel, then the speed can reach to 2400Mbps







in-tel AX210


IEEE 802.11a/b/g/n/ac WiFi and BT5.0 +HS (WiFi: PCI-E, BT: USB)



Frequency Range

WiFi: 2.4GHz, 5.8GHz

BT: 2402MHz~2483MHz


2*5 dBi

Transmission Rate

2.4G up to 574Mbps, 5.8G up to 2400Mbps

Operating System

Microsoft Windows* 10, Linux*, Chrome OS*

Dimensions (H x W x D)

M.2 2230: 22mm x 30mm x 2.4mm [1.5mm Max (Top Side)/ 0.1mm Max (Bottom Side)]

M.2 1216: 12mm x 16mm x 1.67 (+-0.08)mm



M.2 2230: 2.83 +/– 0.3 g
M.2 1216: 0.67 +/– 0.1 g

Radio ON/OFF Control


Connector Interface

M.2: PCIe, USB

Operating Temperature (Adapter Shield)

0°C to +80°C

Humidity Non-Operating

50% to 90% RH non-condensing (at temperatures of 25°C to 35°C)

Wi-Fi Alliance8

Wi-Fi CERTIFIED* a, b, g, n, ac with wave 2 features, WMM*, WMM*-Power Save, WPA*, WPA2*, WPS*, PMF*, Wi-Fi Direct*, Wi-Fi Miracast* , Wi-Fi Agile Multiband*, Wi-Fi Optimized Connectivity*, Wi-Fi Location, Passpoint*, Wi-Fi Aware*, and Wi- Fi TimeSync*

IEEE WLAN Standard

IEEE 802.11-2016 and select amendments (selected feature coverage)
IEEE 802.11a, b, g, n, ac, ax, d, e, h, i, k, r, u, v, w, ai; Fine Timing Measurement based on 802.11-2016


BT 5.0

Security Methods

WPA* and WPA2* Personal and Enterprise; WPA3* (pending OS support)


Product Pictures


Packaging & Shipping

What is the packaging for option?

1.Blister package or color gift package

2.Standard Carton:K=K


What is the shipping way?

UPS/DHL/TNT/EMS/FedEx and any other shipping way as you prefered.

Pls contact us directly and we will use your preferred ways.

Our Services

What are the payment terms ?

We accept T/T, Western Union, Paypal,L/C if over 100000$ and so on.

Over 1000pcs,we can do OEM  and accept 30% deposit in advance .


What is the warranty?
1. Warranty:12 months.
2. comprehensive after-sales service, including quality service, guidance services,We focus on customer needs in every detail.Please contact us if you need our detail warranty term.


Company Information

        Established in 2004, EDUP is the global brand name for Shenzhen EDUP Electronics Technology Co., Ltd. We are a professional company and exporter specialized in Wireless products. We are located in Shenzhen, with convenient transportation access. All of our products comply wtih international quality standards and are greatly apprecaiated in a variety of different markets throughout the world.
