Normally Closed&Normally Open Magnetic Surface Mount Reed Switch Slide Linear Position Displacement Industrial Magnetic Sensor
- Category: >>>
- Supplier: Hangzhou Sakady Sensor Co. Ltd.
Share on (1600573746089):
Product Overview
Description
Product Overview
●High sensitivity
●Long life and high reliability
●Reverse polarity protection, overload protection, surge protection function●Long life and high reliability
●It can be used in harsh environment without being affected by pollution, dust, etc
PRODUCT SPECIFICATIONS
Model | CL-52P-Y | CL-52N-Y | CL-52P-Y |
Wiring method | 2-wire | 3-wire | 3-wire |
Switch logic | Reed tube SPST NO | Reed tube SPST NO | Reed tube SPST NO |
Output contact form | Contact connection | Contact connection NPN | Contact connection PNP |
Supply voltage | 5 ~ 24V DC | 5 ~ 24V DC | 5 ~ 24V DC |
Max. current | 100mA MAX. | 100mA MAX. | 100mA MAX. |
Maximum contact capacity | 10W MAX. | 10W MAX. | 10W MAX. |
Consumed current | 10W MAX. | 10mA MAX. | 10mA MAX. |
Voltage drop | 3.7V MAX. | 3.7V MAX. | 3.7V MAX. |
Leakage current | <0.01mA | <0.01mA | <0.01mA |
Indicator light | Red LED | Red LED | Red LED |
Maximum switching frequency | 500Hz | 500Hz | 500Hz |
Ambient temperature | (-10C°~ +70C° | (-10C°~ +70C° | (-10C°~ +70C° |
Impact resistance | 30G | 30G | 30G |
Resistant to vibration | 9G | 9G | 9G |
Protection Grade | IP 67 | IP 67 | IP 67 |
Protection circuit | No | No | No |
Connection | RVV2 X 0.5mm²2m | 0.3m RVV2 X 0.5mm²+M8plug | 0.3m RVV2 X 0.5mm²+M8plug |
Model | CL-35R-Y | CL-35N-Y | CL-35P-Y |
Wiring method | 2-wire | 3-wire | 3-wire |
Switch logic | Reed tube SPST NO | Reed tube SPST NO | Reed tube SPST NO |
Output contact form | Contact connection | Contact connection NPN | Contact connection PNP |
Supply voltage | 5 ~ 24V DC | 5 ~ 24V DC | 5 ~ 24V DC |
Max. current | 100mA MAX. | 100mA MAX. | 100mA MAX. |
Maximum contact capacity | 10W MAX. | 10W MAX. | 10W MAX. |
Consumed current | 10mA MAX. | 10mA MAX. | 10mA MAX. |
Voltage drop | 3.7V MAX. | 3.7V MAX. | 3.7V MAX. |
Leakage current | <0.01mA | <0.01mA | <0.01mA |
Indicator light | Red LED | Red LED | Red LED |
Maximum switching frequency | 500Hz | 500Hz | 500Hz |
Ambient temperature | (-10C°~ +70C° | (-10C°~ +70C° | (-10C°~ +70C° |
Impact resistance | 30G | 30G | 30G |
Resistant to vibration | 9G | 9G | 9G |
Protection Grade | IP 67 | IP 67 | IP 67 |
Protection circuit | No | No | No |
Connection | RVV2 X 0.5mm²2m | RVV2 X 0.5mm²2m | RVV2 X 0.5mm²2m |
Model | CL-01R-Y | CL-01N-Y | CL-01P-Y |
Wiring method | 2-wire | 3-wire | 3-wire |
Switch logic | Reed tube SPST NO | Reed tube SPST NO | Reed tube SPST NO |
Output contact form | Contact connection | Contact connection NPN | Contact connection PNP |
Supply voltage | 5 ~ 24V DC | 5 ~ 24V DC | 5 ~ 24V DC |
Max. current | 100mA MAX. | 100mA MAX. | 100mA MAX. |
Maximum contact capacity | 10W MAX. | 10W MAX. | 10W MAX. |
Consumed current | No | 10mA MAX. | 10mA MAX. |
Voltage drop | 3.7V MAX. | 0.3V MAX. | 0.3V MAX. |
Leakage current | <0.01mA | <0.01mA | <0.01mA |
Indicator light | Red LED | Red LED | Red LED |
Maximum switching frequency | 500Hz | 500Hz | 500Hz |
Ambient temperature | (-10C°~ +70C° | (-10C°~ +70C° | (-10C°~ +70C° |
Impact resistance | 30G | 30G | 30G |
Resistant to vibration | 9G | 9G | 9G |
Protection Grade | IP 67 | IP 67 | IP 67 |
Protection circuit | No | No | No |
Connection | RVV2 X 0.5mm²2m | RVV2 X 0.5mm²2m | RVV2 X 0.5mm²2m |
Model | CL-08R-Y | CL-08N-Y | CL-08P-Y |
Wiring method | 2-wire | 3-wire | 3-wire |
Switch logic | Reed tube SPST NO | Reed tube SPST NO | Reed tube SPST NO |
Output contact form | Contact connection | Contact connection NPN | Contact connection PNP |
Supply voltage | 5 ~ 24V DC | 5 ~ 24V DC | 5 ~ 24V DC |
Max. current | 100mA MAX. | 100mA MAX. | 100mA MAX. |
Maximum contact capacity | 10W MAX. | 10W MAX. | 10W MAX. |
Consumed current | 10mA MAX. | 10mA MAX. | 10mA MAX. |
Voltage drop | 3.7V MAX. | 3.7V MAX. | 3.7V MAX. |
Leakage current | <0.01mA | <0.01mA | <0.01mA |
Indicator light | Red LED | Red LED | Red LED |
Maximum switching frequency | 500Hz | 500Hz | 500Hz |
Ambient temperature | (-10C°~ +70C° | (-10C°~ +70C° | (-10C°~ +70C° |
Impact resistance | 30G | 30G | 30G |
Resistant to vibration | 9G | 9G | 9G |
Protection Grade | IP 67 | IP 67 | IP 67 |
Protection circuit | No | No | No |
Connection | RVV2 X 0.5mm²2m | RVV2 X 0.5mm²2m | RVV2 X 0.5mm²2m |
Model | CL-25R-Y | CL-25N-Y | CL-25P-Y |
Wiring method | 2-wire | 3-wire | 3-wire |
Switch logic | Reed tube SPST NO | Reed tube SPST NO | Reed tube SPST NO |
Output contact form | Contact connection | Contact connection NPN | Contact connection PNP |
Supply voltage | 5 ~ 24V DC | 5 ~ 24V DC | 5 ~ 24V DC |
Max. current | 100mA MAX. | 100mA MAX. | 100mA MAX. |
Maximum contact capacity | 10W MAX. | 10W MAX. | 10W MAX. |
Consumed current | 10mA MAX. | 10mA MAX. | 10mA MAX. |
Voltage drop | 3.7V MAX. | 3.7V MAX. | 3.7V MAX. |
Leakage current | <0.01mA | <0.01mA | <0.01mA |
Indicator light | Red LED | Red LED | Red LED |
Maximum switching frequency | 500Hz | 500Hz | 500Hz |
Ambient temperature | (-10C°~ +70C° | (-10C°~ +70C° | (-10C°~ +70C° |
Impact resistance | 30G | 30G | 30G |
Resistant to vibration | 9G | 9G | 9G |
Protection Grade | IP 67 | IP 67 | IP 67 |
Protection circuit | No | No | No |
Connection | RVV2 X 0.5mm²2m | RVV2 X 0.5mm²2m | RVV2 X 0.5mm²2m |
Product Picture
Why Choose Us
Buyer comments
FAQ
Q1: What is the MOQ? | ||||||||
A : 1 pcs for our own available designs. | ||||||||
Q2: Can I put my logo on the product? | ||||||||
A : Yes, we can print your logo on the items. | ||||||||
Q3: How about the quality of your products? | ||||||||
A : Our products have passed TUV, CCC and CE certification. | ||||||||
Q4: How long is the delivery time of 1000 products ? | ||||||||
A : 7 days | ||||||||
Q5: Can I get a lower price if I order large quantities? | ||||||||
A : Yes, Cheaper prices with bigger size orders | ||||||||
Q6: Can I get a sample? | ||||||||
A : Of course, but you need to pay the minimum sample fee | ||||||||
Q7: Can I add or delete items from my order if I change mind? | ||||||||
A : Yes, but you need to tell us asap, if your order has been done in our production line, we cannot change it. | ||||||||
Q8: How can you guarantee the production quality? | ||||||||
A : The quality of our products has passed TUV, CE, CCC, IS09000 certification. We have 15+ years OEM labeling experience with global top sensor brands. | ||||||||
