FIBERTOP for Brocade XBR SFP25G1330 10 Compatible 25G CWDM SFP28 1330nm 10km fiber optic Transceiver module
- Category: >>>
- Supplier: Shen,Zhen,Fibertop,Technology,Co.,Ltd
Share on:
Product Overview
Description
Automated Production Process
√ 20+ Years Experience as Expert of Optical Transceivers
√ Pursue Excellence,Create Quality
√ Outstanding Product Performance
Product Details
Features
• Functionally similar to Brocade XBR-SFP25G1330-10 transceiver
• Support for 25Gb/s data rate
• Uncooled CWDM DFB transmitter, PIN photo-detector
• Distance up to 10km on single mode fiber
• Low power consumption<1.2W
• Built-in digital diagnostic functions
• Single 3.3V power supply
• ROHS compliant and lead-free
Specification
Compatible OEM Part Number | XBR-SFP25G1330-10 | FIBERTOP Part Number | SFP-CD33T5-10DC |
Form Factor | SFP28 | Data Rate | 25 Gb/s |
Wavelength | 133nm CWDM | Fiber Type | SMF |
Max Distance | 10KM | Optical Components | CWDM_DFB+PIN |
Transmitter Power | 0~ 6dBm | Extinction ratio | > 3.5dB |
Receiver Sensitivity | < -13.3 Bm | Receiver Overload | >2dBm |
Connector | Double LC | Digital Diagnostic Monitoring | Yes |
Environment | Operating: 0°C to 70°C Storage: -40°C to 85°C | Weight | 0.03 kg |
25G Ethernet 25G CRPI | IEC/EN 61000-4-2, IEC-60825 RoHS |
Order Information
FIBERTOP | DESCRIPTION |
SFP-CD27T5-10DC | 25G CWDM SFP28 1270nm 10km DOM Duplex LC SMF Optical Transceiver Module |
SFP-CD29T5-10DC | 25G CWDM SFP28 1290nm 10km DOM Duplex LC SMF Optical Transceiver Module |
SFP-CD31T5-10DC | 25G CWDM SFP28 1310nm 10km DOM Duplex LC SMF Optical Transceiver Module |
SFP-CD33T5-10DC | 25G CWDM SFP28 1330nm 10km DOM Duplex LC SMF Optical Transceiver Module |
SFP-CD35T5-10DC | 25G CWDM SFP28 1350nm 10km DOM Duplex LC SMF Optical Transceiver Module |
SFP-CD37T5-10DC | 25G CWDM SFP28 1370nm 10km DOM Duplex LC SMF Optical Transceiver Module |
Brocade XBR-SFP25G1330-10 Compatible 25G CWDM SFP28 DOM Optical Transceiver Module for Data Center and Telecom (SMF, 1330nm, 10km,LC, DOM) This Brocade XBR-SFP25G1330-10 Compatible SFP28 transceiver provides 25GBase-CWDM throughput up to 10km over single mode fiber (SMF) using a wavelength of 1330nm via an LC duplex connector. It provides 25GBASE Ethernet connectivity option for 25G Ethernet, telecom and data center. It is fully compliant with the SFP28 MSA, CPRI and eCPRI standard. |
Daily shipment
Click to learn more
Production Process
Production line
Welding
Visual inspection
Assembly
Test
Cleaning
Ageing
Compatibility Test
Packing
Efficiently Supply Chain
High Quality | High Reliability | Win-Win Partnership |
Our Qualifications&Certificates
Completely management system | ISO9001/ISO14001/ISO45001 |
Reliability Product certificate | RoHs/UL/CE/FCC |
Independent R&D Enterprise | 100+ technical patent certificates |
Package & Shipping
Our package defaults to single pack and 10 packs, and we support customized package;
Currently we can support DHL , if you need to use other logistics, please contact with us.
Currently we can support DHL , if you need to use other logistics, please contact with us.
FAQ
Q1:Can I have a sample order? What is your MOQ?
Q4:What is operating temperature range of optical modules?
A4:Commercial temperature range(COM) : 0 to 70℃
Extended temperature range(EXT):-20 to 85℃
Industrial temperature range(IND)::-40 to 85℃
A1:Yes, sample order is available for your testing and checking quality. Mixed samples are acceptable, our MOQ is just one piece.
Q2:Do you have customization service?
A2:Yes. You can use your logo,other services please talk with us.
Q3:What is your after-sales service?
A3:All our customers can get three years quality warranty, and lifetime technical support.
A3:All our customers can get three years quality warranty, and lifetime technical support.
Q4:What is operating temperature range of optical modules?
A4:Commercial temperature range(COM) : 0 to 70℃
Extended temperature range(EXT):-20 to 85℃
Industrial temperature range(IND)::-40 to 85℃
