High quality liquid 26G water level sensor non contact gauge radar measuring instruments
- Category: >>>
- Supplier: Hangzhou Sinomeasure Automation Technology Co. Ltd.
Share on (1600580245675):
Product Overview
Description
Our service
Our Aim :
Customer centric, striving for this.
Our Vision :
To make the world use China's top instruments.
Our Team :
Committed to Quality&Quality control (QC) system&ISO9001
Satisfaction Guaranteed.
Fast Response time Guaranteed.
A Wide Spectrum Of Skills & Experience.
Customer centric, striving for this.
Our Vision :
To make the world use China's top instruments.
Our Team :
Committed to Quality&Quality control (QC) system&ISO9001
Satisfaction Guaranteed.
Fast Response time Guaranteed.
A Wide Spectrum Of Skills & Experience.
Products Description
* Solid level measurement *
SIN-RD903 | ||
Application | solid chat, strong dust,crystallize, condensation | |
Range | 0-70m | |
Frequency | 26GHZ | |
Accuracy | ± 15mm | |
Temperature | 40-130 ℃ (250 ℃ high temperature type) | |
Pressure | -0.1-4.0MPa | |
-0.1-0.3MPa (universal flange) | ||
Installation | universal flange | |
Output | 4-20mA (Hart optional), RS485 | |
SIN-RD904 | ||
Application | solid chat, strong dust,crystallize, condensation | |
Range | 0-80m | |
Frequency | 26GHZ | |
Accuracy | ± 15mm | |
Temperature | 40-130 ℃ (250 ℃ high temperature type) | |
Pressure | -0.1-4.0MPa | |
Installation | Thread, universal flange | |
Output | 4-20mA (Hart optional), RS485 | |
SIN-RD905 | ||
Application | solid chat, strong dust,crystallize, condensation | |
Range | 0-30m | |
Frequency | 26GHZ | |
Accuracy | ± 10mm | |
Temperature | -40-130 ℃ (250 ℃ high temperature type) | |
Pressure | -0.1-4.0MPa | |
-0.1-0.1MPa (universal flange) | ||
Installation | Universal flange | |
Output | 4-20mA (Hart optional), RS485 | |
* Tank level measurement *
SIN-RD901 | ||
Application | Various corrosive liquids | |
Range | 0-10m | |
Frequency | 26GHZ | |
Accuracy | ± 5mm | |
Temperature | -40-130 ℃ | |
Pressure | -0.1-0.3MPa | |
Installation | Thread,Flange | |
Output | 4-20mA (Hart optional), RS485 | |
SIN-RD902 | ||
Application | High temperature,high pressure, slightly corrosive liquid | |
Range | 0-30m | |
Frequency | 26GHZ | |
Accuracy | ± 5mm | |
Temperature | -40-130 ℃ | |
Pressure | -0.1-0.3MPa | |
Installation | Thread,Flange | |
Output | 4-20mA (Hart optional), RS485 | |
* Working condition with steam *
SIN-RD906 | ||
Application | Hygienic liquid storage tank, strong corrosive liquid | |
Range | 0-5m (blind zone 150mm) | |
Frequency | 26GHZ | |
Accuracy | ± 3mm | |
Temperature | -40-130 ℃ | |
Pressure | Normal | |
Installation | Flange | |
Output | 4-20mA (Hart optional), RS485 | |
SIN-RD902T | ||
Application | Corrosive liquids, steam, volatile gases | |
Range | 0-20m (blind zone 300mm) | |
Frequency | 26GHZ | |
Accuracy | ± 3mm | |
Temperature | -40-150 ℃ | |
Pressure | -0.1-2.0MPa | |
Installation | Flange | |
Output | 4-20mA (Hart optional), RS485 | |
* Water conservancy application *
SIN-RD908 | ||
Application | River, reservoir,tidal flat | |
Range | 0-70m | |
Frequency | 26GHZ | |
Accuracy | ± 3mm | |
Temperature | -40-150 ℃ | |
Installation | G1/2 Thread, bracket, flange | |
Output | 4-20mA (Hart optional), RS485 | |
Ingress protection | IP67 | |
* Low frequency radar level meter *
SIN-RD801 | ||
Application | Liquid, slightly corrosive liquid | |
Range | 0-20m | |
Frequency | 6GHZ | |
Accuracy | ± 10mm | |
Cable | Stick (PP/PTFE) | |
Temperature | -40-130 ℃ | |
Pressure | -0.1-0.3MPa | |
Installation | Thread, Flange (optional) | |
Output | 4-20mA (Hart optional), RS485 | |
SIN-RD802 | ||
Application | strong corrosive liquid | |
Range | 0-20m | |
Frequency | 6GHZ | |
Accuracy | ± 10mm | |
Cable | Stick (PTFE) | |
Temperature | -40-130 ℃ (180℃ high temperature) | |
Pressure | -0.1-01.6MPa | |
Installation | Flanged flange | |
Output | 4-20mA (Hart optional), RS485 | |
SIN-RD803 | ||
Application | Pressure , volatile gases | |
Range | 0-35m | |
Frequency | 6GHZ | |
Accuracy | ± 10mm | |
Temperature | -40-130 ℃ (250℃ high temperature) | |
Pressure | -0.1-4MPa | |
Installation | Flanged flange | |
Output | 4-20mA (Hart optional), RS485 | |
* Guided wave radar level meter*
SIN-RD701 | ||
Application | Liquid, solid | |
Range | 0-30m | |
Frequency | 500MHZ-1.8GHz | |
Accuracy | ± 10mm | |
Antenna | Stick,Cable | |
Temperature | -40-130 ℃ (250℃ high temperature) | |
Pressure | -0.1-4MPa | |
Installation | Tread, Flange | |
Output | 4-20mA (Hart optional), RS485 | |
SIN-RD702 | ||
Application | Liquid, strong corrosive liquid | |
Range | 0-20m | |
Frequency | 500MHZ-1.8GHz | |
Accuracy | ± 10mm | |
Antenna | Stick, Cable (PTFE) | |
Temperature | -40-130 ℃ (220℃ high temperature) | |
Pressure | -0.1-4MPa | |
Installation | Tread, Flange | |
Output | 4-20mA (Hart optional), RS485 | |
SIN-RD703 | ||
Application | Solid powder( for example cement silo) | |
Range | 0-30m | |
Frequency | 500MHZ-1.8GHz | |
Accuracy | ± 10mm | |
Antenna | Two cable | |
Temperature | -40-130 ℃ | |
Pressure | -0.1-0.6MPa | |
Installation | Tread, Flange | |
Output | 4-20mA (Hart optional), RS485 | |
SIN-RD704 | ||
Application | Low dielectric constant liquid(for example： deionized water, deoxygenated water, etc） | |
Range | 0-6m | |
Frequency | 500MHZ-1.8GHz | |
Accuracy | ± 5mm | |
Antenna | Tube | |
Temperature | -40-130 ℃ | |
Pressure | -0.1-0.6MPa | |
Installation | Tread, Flange | |
Output | 4-20mA (Hart optional), RS485 | |
