Product Description





Description:


PTFE shrink tubing has a very high continuous use temperature (260°C), and outstanding chemical resistance. It is available in1.7:1 and 4:1 shrink ratios, While it is the best of the entire fluoropolymer heat shrink tubing family, PTFE is also the most difficult to shrink due to its extremely high shrinking temperature (350-450°C).





Application:





High temperature protection.


Automotive.


Printing Press.


Medical insulation.


Cable insulation.





Features and Benefits:





Wide work temperature: -60°C to +260°C


UV resistance


Excellent Chemical resistance.


Flame resistant UL 94 V0





Properties:
























































Property



Test Method



Typical Performance



 Density



ASTM D792



2.12-2.17 g/cc



 hardness shore D







60D



Tensile Strength(Mpa)



ASTM D638



27-35Mpa



 Elongation(%)



ASTM D638



280-400%



 flammability



UL 94



VW-0



 water absorption



ASTM D570



≤ 0.01%



thermal conductivity



ASTM C177



0.25 W/m-k



 dielectric constant



short time ASTM D149



30kv/1mm



Shrink temperature







380°C






Specification:


 PTFE heat shrink tube:




























































Size



ID



  Wall thickenss






 ID recoveried



Φ1.5



1.8±0.2



0.07±0.04



0.4±0.1



Φ2.0



2.2±0.2



0.07±0.04



0.5±0.1



Φ3.0



3.2±0.2



0.07±0.04



0.7±0.15



Φ4



4.3±0.2



0.07±0.04



1.2±0.2



Φ5



5.5±0.2



0.07±0.04



1.4±0.2



Φ6



6.3±0.2



0.10±0.04



1.7±0.2



Φ8



8.3±0.5



0.10±0.04



2±0.2



Φ9



9



0.10±0.04



2.3±0.2



.jpg6shrink tubing

FAQ




 1.what can you buy from us?


Shrink Terminal,Solder Sleeve,Insulation Terminal,Shrink Tubing,Antenna





2. What is the standard production time for each order?


-Production time around 7-15days depends on the product and quantity. Some items have in stock, we can deliver any time you want.





3. Are you able to provide custom packaging?


-Yes, but some items need MOQ to make custom packing.





4. How long time the shipment will take?


-It will take 5-7days if buy air and 20-30days by sea.





5. May I have a look at your catalog?


- Sure. We have the most professional catalog here. Or maybe you tell us where you use it then we will recommend the related products to save time.





6. Will I get your sample?


- Sure. The sample is Free And believes that our quality is the best! And we are professional.





7. Could you provide OEM service?


- Sure.Welcome to build a long relationship with us. We believe that we can provide the best OEM service for you.





8. How can we make sure the quality and lead time?


-We have a deep relationship with Alibaba, they will inspect our quality and lead time. So don’t worry.
