High efficiency Deye SUN1800G3 EU 230 1800W Single phase 4 MPPT Micro Inverter connect PV modules Micro inverter.
- Category: >>>
- Supplier: Chasun Solar Co. Ltd.
Share on (1600580524133):
Product Overview
Description
Product Description
Specification
Technical Specifications | ||||||||
Model | SUN1300G3-EU-230 | SUN1600G3-EU-230 | SUN1800G3-EU-230 | SUN2000G3-EU-230 | ||||
Input Data (DC) | ||||||||
Recommended input Power (STC) | 210~400W (4 Pieces) | 210~500W (4 Pieces) | 210~500W (4 Pieces) | 210~600W (4 Pieces) | ||||
Maximum input DC Voltage | 60V | |||||||
MPPT Voltage Range | 25~55V | |||||||
Operating DC Voltage Range | 20~60V | |||||||
Max. DC Short Circuit Current | 16A | |||||||
Max. input Current | 10.5A×4 | 12.5A×4 | 12.5A×4 | 12.5A×4 | ||||
Output Data (AC) | ||||||||
Rated output Power | 1300W | 1600W | 1800W | 2000W | ||||
Maximum output Power | 1430W | 1760W | 1980W | 2200W | ||||
Maximum output Current | 6.2A | 7.7A | 8.6A | 9.6A | ||||
Nominal Voltage / Range | 230V / 184-265V | |||||||
Nominal Frequency / Range | 50 / 60Hz | |||||||
Extended Frequency/Range | 45~55Hz / 55~65Hz | |||||||
Power Factor | >0.99 | |||||||
Maximum units per branch | 4 | 4 | 3 | 3 | ||||
Efficiency | ||||||||
CEC Weighted Efficiency | 95% | |||||||
Peak Inverter Efficiency | 96.5% | |||||||
Static MPPT Efficiency | 99% | |||||||
Night Time Power Consumption | 50mW | |||||||
Mechanical Data | ||||||||
Ambient Temperature Range | -40~65℃ | |||||||
Size (mm) | 267W×300H×42.5D (Without mounting bracket and cable) | |||||||
Weight (kg) | 5.2 | |||||||
Cooling | Natural cooling | |||||||
Enclosure Environmental Rating | IP67 | |||||||
Features | ||||||||
Compatibility | Compatible with 60~72 cell PV modules | |||||||
Communication | Power line / WIFI / Zigbee | |||||||
Compliance | EN50549、VDE0126、VDE4105、IEC62109、CE、INMETRO | |||||||
Warranty | 10 years | |||||||
Company Profile
Jinhua Chasun Solar Technology Co.,Ltd is the subsidiary corporationan of Chasun Group Co.,Ltd. Which are an international high-tech and growing group company, specializing in the design, manufacture, sales, installation and maintenance of solar power products.
Chasun solar has a powerful team of specialists in photovoltaic, inverter, battery,Controller and solar generator technology,
product development, and project management. Every one of them is an authority in its field and has more than a decade of experience.
We aiming at becoming “The expert of solar power generation”.
Chasun insist on the objective of “green energy for our lives”, continuously innovating, forging ahead, willing to work together with the new and old customers to contribute to the development of solar applications, and to strive to create a beautiful green pollution-free environment for human society. Make a contribution to the green world, starting with the choice of Chasun solar. Chase Sun Energy, Enjoy New Live!
product development, and project management. Every one of them is an authority in its field and has more than a decade of experience.
We aiming at becoming “The expert of solar power generation”.
Chasun insist on the objective of “green energy for our lives”, continuously innovating, forging ahead, willing to work together with the new and old customers to contribute to the development of solar applications, and to strive to create a beautiful green pollution-free environment for human society. Make a contribution to the green world, starting with the choice of Chasun solar. Chase Sun Energy, Enjoy New Live!
Packing & Delivery
FAQ
Q1: Do your company a trading company or manufacturer?
A1: Chasun is a Group Company which have solar panel factory, Inverter factory.solar system factory. We also do Construction Engineering. Whatproofing Engineering. Mould Making. Solar industry is our main products for exporting.
A1: Chasun is a Group Company which have solar panel factory, Inverter factory.solar system factory. We also do Construction Engineering. Whatproofing Engineering. Mould Making. Solar industry is our main products for exporting.
Q2: How long can you delivery my order?
A2: Usually we need 15 days to prepare your order after receiving the deposit..
Q3: Can you export Huawei inverter?
A3: Yes, We can, We have exported big quantity huawei inverter, we have very full experience about exporting huawei inverter
Q4: What's your payment terms ?
A4: By T/T,LC AT SIGHT,30% deposit in advance, balance 70% before shipment.
Q5: What do we need to monitor the project?
A5: The Smart Dongle is necessary for monitoring the project.
Q6: What is inverter warranty ?
A6: 5 years warranty
Q7: Do you inverter are Chinese type or International type?
A7:All our inverter are international type with wifi.
A2: Usually we need 15 days to prepare your order after receiving the deposit..
Q3: Can you export Huawei inverter?
A3: Yes, We can, We have exported big quantity huawei inverter, we have very full experience about exporting huawei inverter
Q4: What's your payment terms ?
A4: By T/T,LC AT SIGHT,30% deposit in advance, balance 70% before shipment.
Q5: What do we need to monitor the project?
A5: The Smart Dongle is necessary for monitoring the project.
Q6: What is inverter warranty ?
A6: 5 years warranty
Q7: Do you inverter are Chinese type or International type?
A7:All our inverter are international type with wifi.
