Product Overview
Description
Dimensional Weight Scanner
Low cost and high accuracy dimensional weight scanner for third-party logistics and wholesale distributors
Dimension weight scanner Introduction:
Dimension weight scanning system (DWS) integrated weight measurement system, modular design, configuration and maintenance is simple, can help enterprises to solve the one-time weighing, volume measurement, bar code recognition, manual input, camera archiving and other five basic functions, the main application Logistics distribution and warehousing links.
Dimension weight scanning system (DWS) integrated weight measurement system, modular design, configuration and maintenance is simple, can help enterprises to solve the one-time weighing, volume measurement, bar code recognition, manual input, camera archiving and other five basic functions, the main application Logistics distribution and warehousing links.
Dimensional weight scanner can capture any shaped parcel’s dimension and weight and store high-quality product images. In addition, you can scan the parcel labels with an integrated barcode scanner and configure the touchscreen to capture any parcel data using custom fields without needing a laptop.
Product Features:
*System software for Windows7 and above operating system;
*System software and warehouse management system compatible;
*Can measure any color / shape of the goods;
*Can be applied to any lighting conditions;
*Can be sorted with the sorting system;
*Customizable combination function can be realized;
*Can be set for continuous or independent operations;
*Can quickly and intuitively display size, weight and size / weight relationship, while calculating freight;
*There is a certain period of time to measure the photo archive.
*System software for Windows7 and above operating system;
*System software and warehouse management system compatible;
*Can measure any color / shape of the goods;
*Can be applied to any lighting conditions;
*Can be sorted with the sorting system;
*Customizable combination function can be realized;
*Can be set for continuous or independent operations;
*Can quickly and intuitively display size, weight and size / weight relationship, while calculating freight;
*There is a certain period of time to measure the photo archive.
Power | AC110-240V,50/60Hz |
Bar Code Type | Code128/ Code39/QR |
Processing Efficiency | 2000-3000pcs/hour |
Weighing Accuracy | ±50g( Based on25kg) |
Applicable Parcel Size | L100-1200 X W100-800 X H40-600mm(Customizable) |
Dimensioning Accuracy | ±10mm |
Scanning Position | 1Surfaces or 5 Surfaces |
Functions | Dimensioning, Weighing, Scanning, Photo Capture |
Interface http | /tcp/485 |
Dimensioning Camera | HIKVISION /Dahua/PERCIPIO XYZ |
Weighing Scale | Yaohua / Cell Kelli |
Scanning Camera | HIKVISION/ Dahua |
Scanning Lenses | HIKVISION/ Dahua |
Scanning Illuminant | HIKVISION/ Dahua |
Dimension weight scanner features:
(1) It can automatically measure the weight and dimension of goods information and upload storage.
(2) It can simultaneously carry out data operations and analysis, with the warehouse management system, can achieve carton selection, freight calculation and other functions, and to optimize the storage space, pick up the process to provide data.
(3) To replace the operation of the measurement process, weighing, scanning, recording the manual operation, your working efficiency can increase 5-10 times, 80% lower operating costs.
(1) It can automatically measure the weight and dimension of goods information and upload storage.
(2) It can simultaneously carry out data operations and analysis, with the warehouse management system, can achieve carton selection, freight calculation and other functions, and to optimize the storage space, pick up the process to provide data.
(3) To replace the operation of the measurement process, weighing, scanning, recording the manual operation, your working efficiency can increase 5-10 times, 80% lower operating costs.
